LI Fu, LI Gui Lian, PANG Hui, LIU Hai Can, XIAO Tong Yang, LI Shuang Jun, LUO Qiao, JIANG Yi, WANG Rui Bai, WAN Kang Lin. Preliminary Study on Drug Susceptibility Profile and Resistance Mechanisms to Macrolides of Clinical Isolates of Non-tuberculous Mycobacteria from China[J]. Biomedical and Environmental Sciences, 2018, 31(4): 290-299. doi: 10.3967/bes2018.037
Citation: LI Fu, LI Gui Lian, PANG Hui, LIU Hai Can, XIAO Tong Yang, LI Shuang Jun, LUO Qiao, JIANG Yi, WANG Rui Bai, WAN Kang Lin. Preliminary Study on Drug Susceptibility Profile and Resistance Mechanisms to Macrolides of Clinical Isolates of Non-tuberculous Mycobacteria from China[J]. Biomedical and Environmental Sciences, 2018, 31(4): 290-299. doi: 10.3967/bes2018.037

Preliminary Study on Drug Susceptibility Profile and Resistance Mechanisms to Macrolides of Clinical Isolates of Non-tuberculous Mycobacteria from China

doi: 10.3967/bes2018.037
Funds:

the National Key Programs of Mega Infectious Diseases 2013ZX10003002-001

the Key Project of the State Key Laboratory for Infectious Disease Prevention and Control 2014SKLID104

More Information
  • Author Bio:

    LI Fu, male, born in 1989, PhD candidate, majoring in pathogeny biology

  • Corresponding author: WANG Rui Bai, Tel/Fax:86-10-58900574, E-mail:wangruibai@icdc.cn; WAN Kang Lin, Tel/Fax:86-10-58900705, E-mail:wankanglin@icdc.cn
  • Received Date: 2017-12-07
  • Accepted Date: 2018-04-02
  • Objective Macrolide susceptibility and drug resistance mechanisms of clinical non-tuberculous mycobacteria (NTM) isolates were preliminarily investigated for more accurate diagnosis and treatment of the infection in China. Methods Four macrolides, including clarithromycin (CLAR), azithromycin (AZM), roxithromycin (ROX), and erythromycin (ERY), were used to test the drug susceptibility of 310 clinical NTM isolates from six provinces of China with the broth microdilution method. Two resistance mechanisms, 23S rRNA and erm, were analyzed with nucleotide sequence analysis. Results Varied effectiveness of macrolides and species-specific resistance patterns were observed. Most Mycobacterium abscessus subsp. massiliense were susceptible and all M. fortuitum were highly resistant to macrolides. All the drugs, except for erythromycin, exhibited excellent activities against slow-growing mycobacteria, and drug resistance rates were below 22.2%. Only four highly resistant strains harbored 2, 058/2, 059 substitutions on rrl and none of other mutations were related to macrolide resistance. G2191A and T2221C on rrl were specific for the M. abscessus complex (MABC). Seven sites, G2140A, G2210C, C2217G, T2238C, T2322C, T2404C, and A2406G, were specifically carried by M. avium and M. intracellulare. Three sites, A2192G, T2358G, and A2636G, were observed only in M. fortuitum and one site G2152A was specific for M. gordonae. The genes erm(39) and erm(41) were detected in M. fortuitum and M. abscessus and inducible resistance was observed in relevant sequevar. Conclusion The susceptibility profile of macrolides against NTM was demonstrated. The well-known macrolide resistance mechanisms, 23S rRNA and erm, failed to account for all resistant NTM isolates, and further studies are warranted to investigate macrolide resistance mechanisms in various NTM species.
  • 加载中
  • [1] Glassroth J. Pulmonary disease due to nontuberculous mycobacteria. Chest, 2008; 133, 243-51. doi:  10.1378/chest.07-0358
    [2] Halstrom S, Price P, Thomson R. Review: Environmental mycobacteria as a cause of human infection. Int J Mycobacteriol, 2015; 4, 81-91. doi:  10.1016/j.ijmyco.2015.03.002
    [3] Moore JE, Kruijshaar ME, Ormerod LP, et al. Increasing reports of non-tuberculous mycobacteria in England, Wales and Northern Ireland, 1995-2006. BMC Public Health, 2010; 10, 612. doi:  10.1186/1471-2458-10-612
    [4] Shah NM, Davidson JA, Anderson LF, et al. Pulmonary Mycobacterium avium-intracellulare is the main driver of the rise in non-tuberculous mycobacteria incidence in England, Wales and Northern Ireland, 2007-2012. BMC Infect Dis, 2016; 16, 195. doi:  10.1186/s12879-016-1521-3
    [5] Wang L, Cheng S, Chen M, et al. The fifth national tuberculosis epidemiological survey in 2010. Chin J Antituber, 2012; 34, 485-508. (In Chinese)
    [6] Wang L, Zhang H, Ruan Y, et al. Tuberculosis prevalence in China, 1990-2010: a longitudinal analysis of national survey data. Lancet, 2014; 383, 2057-64. doi:  10.1016/S0140-6736(13)62639-2
    [7] Brown-Elliott BA, Wallace RJ Jr. Clinical and taxonomic status of pathogenic nonpigmented or late-pigmenting rapidly growing mycobacteria. Clin Microbiol Rev, 2002; 15, 716-46. doi:  10.1128/CMR.15.4.716-746.2002
    [8] Kang YA, Koh WJ. Antibiotic treatment for nontuberculous mycobacterial lung disease. Expert Rev Respir Med, 2016; 10, 557-68. doi:  10.1586/17476348.2016.1165611
    [9] Mougari F, Loiseau J, Veziris N, et al. Evaluation of the new GenoType NTM-DR kit for the molecular detection of antimicrobial resistance in non-tuberculous mycobacteria. J Antimicrob Chemother, 2017; 72, 1669-77. doi:  10.1093/jac/dkx021
    [10] Alvarez-Elcoro S, Enzler MJ. The macrolides: erythromycin, clarithromycin, and azithromycin. Mayo Clin Proc, 1999; 74, 613-34. doi:  10.4065/74.6.613
    [11] Fyfe C, Grossman TH, Kerstein K, et al. Resistance to macrolide antibiotics in public health pathogens. Cold Spring Harb Perspect Med, 2016; 6, a025395. http://cn.bing.com/academic/profile?id=b8d4ab56feba8aefee5ffc3d2e4930c4&encoded=0&v=paper_preview&mkt=zh-cn
    [12] Nasiri MJ, Haeili M, Ghazi M, et al. New insights in to the intrinsic and acquired drug resistance mechanisms in mycobacteria. Front Microbiol, 2017; 8, 681. doi:  10.3389/fmicb.2017.00681
    [13] Nash KA, Andini N, Zhang Y, et al. Intrinsic macrolide resistance in rapidly growing mycobacteria. Antimicrob Agents Chemother, 2006; 50, 3476-8. doi:  10.1128/AAC.00402-06
    [14] Zhang YY, Li YB, Huang MX, et al. Novel species including Mycobacterium fukienense sp. is found from tuberculosis patients in Fujian Province, China, using phylogenetic analysis of Mycobacterium chelonae/abscessus complex. Biomed Environ Sci, 2013; 26, 894-901. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=swyx201311004&dbname=CJFD&dbcode=CJFQ
    [15] Nguyen L, Chinnapapagari S, Thompson CJ. FbpA-Dependent biosynthesis of trehalose dimycolate is required for the intrinsic multidrug resistance, cell wall structure, and colonial morphology of Mycobacterium smegmatis. J Bacteriol, 2005; 187, 6603-11. doi:  10.1128/JB.187.19.6603-6611.2005
    [16] Braibant M, Gilot P, Content J. The ATP binding cassette (ABC) transport systems of Mycobacterium tuberculosis. FEMS Microbiol Rev, 2000; 24, 449-67. doi:  10.1111/j.1574-6976.2000.tb00550.x
    [17] CLSI. Susceptibility testing of mycobacteria, Nocardiae, and other aerobic actinomycetes; approved standard—second edition. Wayne, PA; Clinical and Laboratory Standards Institute. 2011.
    [18] Wallace RJ, Meier A, Brown BA, et al. Genetic basis for clarithromycin resistance among isolates of Mycobacterium chelonae and Mycobacterium abscessus. Antimicrob Agents Chemother, 1996; 40, 1676-81. doi:  10.1164/rccm.200905-0704OC
    [19] Bastian S, Veziris N, Roux AL, et al. Assessment of clarithromycin susceptibility in strains belonging to the Mycobacterium abscessus group by erm(41) and rrl sequencing. Antimicrob Agents Chemother, 2011; 55, 775-81. doi:  10.1128/AAC.00861-10
    [20] Nash KA, Brown-Elliott BA, Wallace RJ Jr. A novel gene, erm(41), confers inducible macrolide resistance to clinical isolates of Mycobacterium abscessus but is absent from Mycobacterium chelonae. Antimicrob Agents Chemother, 2009; 53, 1367-76. doi:  10.1128/AAC.01275-08
    [21] Kirst HA, Sides GD. New directions for macrolide antibiotics: pharmacokinetics and clinical efficacy. Antimicrob Agents Chemother, 1989; 33, 1419-22. doi:  10.1128/AAC.33.9.1419
    [22] Hirama T, Shiono A, Egashira H, et al. PCR-based rapid identification system using bridged nucleic acids for detection of clarithromycin-resistant Mycobacterium avium-M. intracellulare Complex Isolates. J Clin Microbiol, 2016; 54, 699-704. doi:  10.1128/JCM.02954-15
    [23] Foo H, van Hal S, Jelfs P, et al. Antimicrobial resistance in non-tuberculous mycobacteria in New South Wales, 2002-2008. Int J Antimicrob Agents, 2009; 34, 182-4. doi:  10.1016/j.ijantimicag.2009.01.013
    [24] Peters DH, Friedel HA, McTavish D. Azithromycin. A review of its antimicrobial activity, pharmacokinetic properties and clinical efficacy. Drugs, 1992; 44, 750-99. doi:  10.2165/00003495-199244050-00007
    [25] Choi GE, Shin SJ, Won CJ, et al. Macrolide treatment for Mycobacterium abscessus and Mycobacterium massiliense infection and inducible resistance. Am J Respir Crit Care Med, 2012; 186, 917-25. doi:  10.1164/rccm.201111-2005OC
    [26] Maurer FP, Castelberg C, Quiblier C, et al. Erm(41)-dependent inducible resistance to azithromycin and clarithromycin in clinical isolates of Mycobacterium abscessus. J Antimicrob Chemother, 2014; 69, 1559-63. doi:  10.1093/jac/dku007
    [27] Struillou L, Cohen Y, Lounis N, et al. Activities of roxithromycin against Mycobacterium avium infections in human macrophages and C57BL/6 mice. Antimicrob Agents Chemother, 1995; 39, 878-81. doi:  10.1128/AAC.39.4.878
    [28] Sodemoto K, Shimada Y, Nishijima C, et al. Successful treatment of cutaneous Mycobacterium chelonae infection with roxithromycin. J Dermatol, 2007; 34, 846-8. doi:  10.1111/jde.2007.34.issue-12
    [29] Koh WJ, Jeon K, Lee NY, et al. Clinical significance of differentiation of Mycobacterium massiliense from Mycobacterium abscessus. Am J Respir Crit Care Med, 2011; 183, 405-10. doi:  10.1164/rccm.201003-0395OC
    [30] Esteban J, Martin-de-Hijas NZ, Garcia-Almeida D, et al. Prevalence of erm methylase genes in clinical isolates of non-pigmented, rapidly growing mycobacteria. Clin Microbiol Infect, 2009; 15, 919-23. doi:  10.1111/j.1469-0691.2009.02757.x
    [31] Renvoise A, Bernard C, Veziris N, et al. Significant difference in drug susceptibility distribution between Mycobacterium avium and Mycobacterium intracellulare. J Clin Microbiol, 2014; 52, 4439-40. doi:  10.1128/JCM.02127-14
    [32] van Ingen J, van der Laan T, Dekhuijzen R, et al. In vitro drug susceptibility of 2275 clinical non-tuberculous Mycobacterium isolates of 49 species in The Netherlands. Int J Antimicrob Agents, 2010; 35, 169-73. doi:  10.1016/j.ijantimicag.2009.09.023
    [33] Lee SH, Yoo HK, Kim SH, et al. The drug resistance profile of Mycobacterium abscessus group strains from Korea. Ann Lab Med, 2014; 34, 31-7. doi:  10.3343/alm.2014.34.1.31
  • 加载中
通讯作者: 陈斌, bchen63@163.com
  • 1.

    沈阳化工大学材料科学与工程学院 沈阳 110142

  1. 本站搜索
  2. 百度学术搜索
  3. 万方数据库搜索
  4. CNKI搜索

Tables(5)

Article Metrics

Article views(2336) PDF downloads(183) Cited by()

Proportional views
Related

Preliminary Study on Drug Susceptibility Profile and Resistance Mechanisms to Macrolides of Clinical Isolates of Non-tuberculous Mycobacteria from China

doi: 10.3967/bes2018.037
Funds:

the National Key Programs of Mega Infectious Diseases 2013ZX10003002-001

the Key Project of the State Key Laboratory for Infectious Disease Prevention and Control 2014SKLID104

Abstract:  Objective Macrolide susceptibility and drug resistance mechanisms of clinical non-tuberculous mycobacteria (NTM) isolates were preliminarily investigated for more accurate diagnosis and treatment of the infection in China. Methods Four macrolides, including clarithromycin (CLAR), azithromycin (AZM), roxithromycin (ROX), and erythromycin (ERY), were used to test the drug susceptibility of 310 clinical NTM isolates from six provinces of China with the broth microdilution method. Two resistance mechanisms, 23S rRNA and erm, were analyzed with nucleotide sequence analysis. Results Varied effectiveness of macrolides and species-specific resistance patterns were observed. Most Mycobacterium abscessus subsp. massiliense were susceptible and all M. fortuitum were highly resistant to macrolides. All the drugs, except for erythromycin, exhibited excellent activities against slow-growing mycobacteria, and drug resistance rates were below 22.2%. Only four highly resistant strains harbored 2, 058/2, 059 substitutions on rrl and none of other mutations were related to macrolide resistance. G2191A and T2221C on rrl were specific for the M. abscessus complex (MABC). Seven sites, G2140A, G2210C, C2217G, T2238C, T2322C, T2404C, and A2406G, were specifically carried by M. avium and M. intracellulare. Three sites, A2192G, T2358G, and A2636G, were observed only in M. fortuitum and one site G2152A was specific for M. gordonae. The genes erm(39) and erm(41) were detected in M. fortuitum and M. abscessus and inducible resistance was observed in relevant sequevar. Conclusion The susceptibility profile of macrolides against NTM was demonstrated. The well-known macrolide resistance mechanisms, 23S rRNA and erm, failed to account for all resistant NTM isolates, and further studies are warranted to investigate macrolide resistance mechanisms in various NTM species.

LI Fu, LI Gui Lian, PANG Hui, LIU Hai Can, XIAO Tong Yang, LI Shuang Jun, LUO Qiao, JIANG Yi, WANG Rui Bai, WAN Kang Lin. Preliminary Study on Drug Susceptibility Profile and Resistance Mechanisms to Macrolides of Clinical Isolates of Non-tuberculous Mycobacteria from China[J]. Biomedical and Environmental Sciences, 2018, 31(4): 290-299. doi: 10.3967/bes2018.037
Citation: LI Fu, LI Gui Lian, PANG Hui, LIU Hai Can, XIAO Tong Yang, LI Shuang Jun, LUO Qiao, JIANG Yi, WANG Rui Bai, WAN Kang Lin. Preliminary Study on Drug Susceptibility Profile and Resistance Mechanisms to Macrolides of Clinical Isolates of Non-tuberculous Mycobacteria from China[J]. Biomedical and Environmental Sciences, 2018, 31(4): 290-299. doi: 10.3967/bes2018.037
  • Non-tuberculous mycobacteria (NTM) are a large group of mycobacteria that are positive for acid-fast staining except Mycobacterium tuberculosis complex (MTBC) and M. leprae. More than 160 species of NTM have been identified, and 40 of these were deemed as pathogenic or opportunistic pathogens.

    There has been a continuous increase in incidences and disease burden of NTM in many regions[1, 2]. The incidence of NTM in the United Kingdom increased from 0.9 per 100, 000 population in 1995 to 2.9 per 100, 000 population in 2006 and continued to increase to 7.6 per 100, 000 in 2012[3, 4]. The nationwide surveillance of tuberculosis (TB) in China showed that the average NTM isolation rate increased from 4.3% (29/682) in 1979 to 11.1% (49/441) in 2000 and 22.9% (83/363) in 2010[5, 6].

    Most NTM strains are intrinsically resistant to the first- and second-line anti-TB agents and difficult to eliminate with treatment regimens commonly used for TB[7, 8]. The resistance profile of NTM is highly species-specific and the clinical course and treatment response of NTM disease may be very variable[9]. Hence, antibiotics prescribed for NTM treatment must have demonstrated activities against the specific species in the antibiotic susceptibility testing. As NTM antibiotic susceptibility testing is time-consuming, demanding several days [rapidly growing mycobacteria (RGM)] or weeks [slowly growing mycobacteria (SGM)] to obtain results depending on the bacterial growth time, more data need to be accumulated on the antibiotic susceptibility and resistance mechanism of NTM species to allow rapid detection of antibiotic-resistant genotype and for clinical applications.

    Macrolides are the preferred choice of the limited antimicrobial agents for the treatment of NTM infections. The in vitro susceptibility test and in vivo clinical treatment outcome of macrolides are well consistent[1, 10]. Resistance to macrolide class of antibiotics is mainly conferred by three different mechanisms as follows: substitution and modification of the 23S rRNA target site by various methyltransferases; drug efflux; and inactivation of the molecules by esterases, hydrolases, transferases, or phosphorylases enzymes[11, 12]. However, only two well-known mechanisms have been reported for mycobacteria, namely, mutations in the 23S rRNA-encoding gene, rrl, at positions 2, 058/2, 059 (Escherichia coli numbering) for acquired resistance and erm genes encoding 23S rRNA methyltransferases for natural resistance[9]. The erm genes have been described only in certain NTM species and have five classes as follows: erm(37) of M. tuberculosis complex, erm(38) of M. smegmatis, erm(39) of M. fortuitum, erm(40) of M. mageritense and M. wolinskyi, and erm(41) of MABC and M. fukienense[13, 14]. Aside from the two mechanisms above, Ag85 mutant of M. smegmatis displayed increased sensitivity to erythromycin (ERY), indicating that the defects in the enzymes and proteins involved in maintaining the cell wall integrity may increase the susceptibility of the organism to macrolides[15]. Some of genes encoding putative ATP-binding cassette (ABC) transport systems could be involved in macrolide export[16]. However, more evidence is needed to demonstrate the role of Ag85 and ABC transport systems in the development of macrolide resistance in mycobacteria. In this study, 310 NTM clinical isolates belonging to six of the most common species in China were tested to comprehensively compare the susceptibility of NTM to four commonly used macrolides in clinical settings and elucidate the roles of the two known resistance mechanisms of NTM.

  • A total of 310 identified NTM clinical isolates from six provincial TB hospitals of China, including Anhui, Fujian, Jiangxi, Inner Mongolia, Hunan, and Sichuan Provinces, were included in the antibiotic susceptibility testing. All strains had been re-verified up to the species level by sequencing of the genes rrs, rpoB, hsp65, ITS, and sodA. All tests performed in this study were conducted in the laboratory of Branch of Tuberculosis, National Institute for Communicable Disease Control and Prevention.

  • Four macrolides used in this study, including ERY, clarithromycin (CLAR), azithromycin (AZM), and roxithromycin (ROX), were purchased from Sigma-Aldrich Co. (St Louis, MO). Minimum inhibitory concentrations (MICs) were determined with the broth microdilution method based on the Alamar Blue Assay (MABA). Briefly, fresh cultures were completely ground and their densities were adjusted to 0.5 McFarland (1.5 × 108 cells/mL) with saline. The suspension was 1:200 diluted with culture medium supplemented with or without 10% oleic acid-albumin-dextrose-catalase (OADC) (BD, Franklin Lakes, NJ, USA) for SGM and RGM, respectively. Serial two-fold dilutions of the antibiotic solutions were prepared in Mueller-Hinton broth (Difco, Detroit, MI, USA) and inoculated with bacterial dilutions. The final reaction system comprised 100 μL antibiotic solution and an equal volume of the bacterial suspension in each well. The plates were sealed and incubated at 37 ℃. The indicator (20 μL Alamar Blue mixed with 50 μL of 5% Tween-80) was added when the drug-free control which was checked daily showed a color change from blue to pink. MIC testing usually ended at 3 to 6 days for RGM and 7 to 11 days for SGM. The lowest drug concentration that inhibited the strain growth and prevented color change was recorded as the MIC value. All tests for each strain were repeated twice. The dilution concentration range was 0.125-256.000 μg/mL for ERY, ROX, and AZM and 0.063-128.000 μg/mL for CLAR. The interpretive criteria of each drug were 8 μg/mL for RGM and 32 μg/mL for SGM, as suggested by the Clinical and Laboratory Standards Institute (CLSI, M24-A2)[17].

  • Boiled DNA template from the fresh cultures was used. The primer set for the amplification of rrl gene was rrl-F, 5'-CCT GCA CGA ATG GCG TAA CG-3' and rrl-R, 5'-CAC CAG AGG TTC GTC CGT C-3'[18]. The in-frame primer sets used to detect erm genes and the reference sequence used for primer design were as follows: erm(37)-F, 5'-CGG TGA GCT CGT GTT TGA CAT C-3' and erm(37)-R, 5' -AGG CCG ACG GTC AGG GTG AAC C-3' (GenBank accession No. AE000516); erm(38)-F, 5'-GAA ATC GTC TCG CGC ACA AAC-3' and erm(38)-R, 5'-TGC TGA CCA ACG TCG TCG AAG-3' (GenBank accession No. AY154657); erm(39)-F, 5'-AGT TCA TCA CGG CCG GCA TGA G-3' and erm(39)-R, 5'-ATC GAA CAA CGC CAC CCA CTG-3' (GenBank accession No. AY487229); erm(40)-F, 5'-TTG ACG GCC ATC GAG ATC GAC-3' and erm(40)-R, 5'-GAC GGT GTG ATG CCG TTG TG-3' (GenBank accession No. AY570506); erm(41)-F, 5'-GCA CTG CGC GAG AAG CTG GCA-3' and erm(41)-R, 5'-GCG GTG GAT GAT GGA AAG-3' (GenBank accession No. EU590124). The sequencing primer set of entire erm(41) was 5'-GCA CTG CGC GAG AAG CTG GCA-3' and 5'-GCA CTG CGC GAG AAG CTG GCA-3'. PCR products of rrl and erm(41) were sequenced (Tsingke BioTech, Beijing, China) and mutations were identified with alignment using MEGA 7.0 software.

  • The antibiotic susceptibility profiles and MIC ranges of 310 NTM clinical isolates are shown in Tables 1 and 2, respectively. The antibiotic resistance of the four macrolides was in the order ERY, AZM, ROX, and CLAR (high to low) and showed obvious species specificity. M. fortuitum and M. gordonae were the two species with the most distinct difference. M. fortuitum isolates were almost 100.0% resistant to all four macrolides, with 32 μg/mL MIC50 and ≥ 128 μg/mL MIC90. Hence, the use of macrolides may be excluded for the treatment of infections caused by M. fortuitum. On the contrary, M. gordonae strains were essentially sensitive to macrolides with ≤ 4 μg/mL MIC90. The clinical isolation rate of M. massiliense was much lower than that of M. abscessus, and only four isolates were included in this study. Except for the two ERY-resistant isolates, all M. massiliense were sensitive to the four macrolides, which showed high antibacterial efficiencies. The resistance observed was similar for other three species, M. abscessus subsp. abscessus, M. avium, and M. intracellulare. Except for ERY, AZM, ROX, and CLAR showed a resistance rate lower than 24% and MIC50 lower than 8 μg/mL.

    Species Number of Strains ERY (n/%) AZM (n/%) ROX (n/%) CLAR (n/%)
    RGM
      M. abscessus subsp. abscessus 52 14/26.9 12/23.1 12/23.1 7/13.5
      M. abscessus subsp. massiliense 4 2/50.0 0/0 0/0 0/0
      M. fortuitum 9 9/100.0 9/100.0 9/100.0 7/77.8
    SGM
      M. avium 63 43/63.5 14/22.2 8/12.7 6/9.5
      M. intracellulare 159 58/35.2 17/10.7 10/6.3 5/3.1
      M. gordonae 23 2/8.7 2/8.7 1/4.3 0/0
      Note. n, number of resistant strains.

    Table 1.  Resistance (%) of 310 NTM Clinical Isolates from China to Four Macrolides

    NTM Species ERY AZM ROX CLAR
    MIC Range MIC50 MIC90 MIC Range MIC50 MIC90 MIC Range MIC50 MIC90 MIC Range MIC50 MIC90
    RGM
      M. abscessus subsp. abscessus 0.030-> 256.000 0.250 64.000 0.030-> 256.000 0.500 64.000 0.030-> 256.000 0.250 64.000 0.030-64.000 0.125 32.000
      M. abscessus subsp. massiliense 2.000-8.000 4.000 8.000 2.000-4.000 2.000 4.000 2.000-4.000 4.000 4.000 0.125-0.500 0.250 0.500
      M. fortuitum 32.000-> 256.000 64.000 > 256.000 16.000-> 256.000 32.000 > 256.000 16.000-128.000 32.000 128.000 1.000-32.000 8.000 32.000
    SGM
      M. avium 0.250-256.000 32.000 256.000 0.060-64.000 8.000 32.000 0.060-64.000 4.000 32.000 ≤0.030-32.000 0.500 16.000
      M. intracellulare 0.125-> 256.000 16.000 128.000 0.125-> 256.000 8.000 32.000 0.125-> 256.000 2.000 8.000 0.030-128.000 0.250 1.000
      M. gordonae 0.030-256.000 0.250 4.000 0.125-64.000 1.000 4.000 0.125-256.000 0.125 4.000 0.030-8.000 0.030 0.500
      Note. MIC50/90, MICs that inhibit 50% and 90% of the isolates, respectively.

    Table 2.  Macrolide MIC Range (μg/mL) of NTM

  • To explore the role of target-site mutation in the development of macrolide resistance in NTM, the 23S rRNA coding gene, rrl, was sequenced and aligned for 143 strains with different MIC levels selected from 310 NTM clinic isolates that were tested for macrolide resistance.

    Only one M. intracellulare strain harbored A2058T mutation and three M. abscessus subsp. abscessus harbored A2059G mutations. These four strains were highly resistant to all four macrolides and exhibited an MIC value as follows: ERY> 256 μg/mL, AZM> 256 μg/mL, ROX> 256 μg/mL, and CLAR ≥ 64 μg/mL.

    Aside from 2, 058/2, 059 sites, a total of 193 point mutations different from those in the E. coli reference sequence were detected in 143 NTM isolates, wherein 134 sites were common in all NTM isolates tested (Table 3). The other 35 sites existed only in a few of the six NTM species (Table 4). These showed species specificity but were unrelated to macrolide MICs. M. abscessus subsp. abscessus and M. abscessus subsp. massiliense belonged to the same fast-growing M. abscessus species. Their sequences were identical at all sites mentioned above. Although these two subspecies could not be distinguished from each other with rrl gene, the two sites G2191A and T2221C allowed differentiation between these species and other four species. The genetic variation in M. avium and M. intracellulare that belonged to the same M. avium complex (MAC) was also very similar. Seven sites, including, G2140A, G2210C, C2217G, T2238C, T2322C, T2404C, and A2406G, were specially carried by these two species, while G2321A was only observed in M. intracellulare. Three sites, A2192G, T2358G, and A2636G, were distinct for M. fortuitum, while G2152A was specific for M. gordonae. The remaining 24 sites were harbored in one or two NTM isolates and these were mutations without any statistical significance. Although we failed to identify any macrolide resistance-related 23S rRNA mutations in this study, these genus- and species-specific sites on rrl gene mentioned above may facilitate strain identification up to the species level.

    Serial Number Position Mutant Number of Strains Serial Number Position Mutant Number of Strains
    1 2019 A→C 107 23 2102 G→T 107
    2 2023 C→A 107 24 2103 C→A 90
    3 2024 G→C 107 C→T 17
    4 2025 C→G 107 25 2105 T→G 107
    5 2026 T→A 107 26 2106 T→G 107
    6 2029 G→A 107 27 2107 G→T 107
    7 2037 A→T 107 28 2108 A→T 107
    8 2038 G→C 107 29 2128 G→A 107
    9 2039 T→G 107 30 2138 G→A 103
    10 2040 G→T 107 G→C 1
    11 2044 C→G 107 G→T 3
    12 2052 A→G 107 31 2139 T→C 80
    13 2057 G→A 107 T→G 23
    14 2070 A→G 107 T→- 4
    15 2076 T→C 107 32 2153 C→T 103
    16 2088 A→G 107 C→G 4
    17 2089 C→T 107 33 2160 C→T 107
    18 2091 C→T 107 34 2163 A→T 107
    19 2094 A→G 106 35 2165 C→G 107
    A→T 1 36 2178 C→T 107
    20 2095 A→T 90 37 2181 T→G 107
    A→C 17 38 2182 -→A 107
    21 2096 C→G 107 39 2184 A→C 107
    22 2097 A→T 101 40 2185 A→G 107
    A→C 6 41 2187 G→A 107
    42 2190 T→G 107 87 2387 C→A 107
    43 2193 T→C 107 88 2388 A→C 103
    44 2195 T→A 81 A→T 4
    T→C 23 89 2400 T→C 107
    T→- 3 90 2401 G→A 107
    45 2204 T→C 107 91 2402 G→C 107
    46 2207 C→A 107 92 2403 T→C 107
    47 2213 A→T 107 93 2409 A→G 107
    48 2220 G→T 107 94 2418 C→G 107
    49 2222 T→C 107 95 2419 C→T 107
    50 2223 G→A 107 96 2420 A→G 107
    51 2233 T→C 107 97 2443 T→C 107
    52 2248 G→A 107 98 2463 A→C 107
    53 2260 C→T 107 99 2464 C→T 107
    54 2261 T→G 107 100 2465 C→T 107
    55 2271 G→A 107 101 2466 G→C 107
    56 2272 A→T 107 102 2476 T→C 107
    57 2283 A→C 107 103 2488 C→G 107
    58 2286 A→C 107 104 2489 G→A 107
    59 2288 G→A 107 105 2490 G→T 107
    60 2295 G→C 107 106 2491 T→G 107
    61 2296 G→C 107 107 2515 A→G 107
    62 2299 A→C 107 108 2518 A→G 107
    63 2301 T→A 107 109 2532 A→G 107
    64 2307 T→A 107 110 2535 T→C 107
    65 2311 A→C 107 111 2549 A→T 107
    66 2312 C→A 107 112 2550 T→G 107
    67 2319 A→T 107 113 2562 A→C 107
    68 2323 T→G 107 114 2563 T→A 107
    69 2331 T→G 103 115 2570 T→C 107
    T→A 4 116 2573 T→C 107
    70 2332 G→T 107 117 2613 C→T 107
    71 2336 T→C 107 118 2619 T→C 107
    72 2340 C→G 107 119 2624 T→C 107
    73 2341 C→G 107 120 2626 G→C 107
    74 2356 C→A 107 121 2630 C→T 107
    75 2357 G→C 107 122 2631 T→C 107
    76 2359 G→T 107 123 2632 G→A 107
    77 2362 G→A 107 124 2635 G→A 107
    78 2363 G→A 101 125 2637 A→C 107
    G→T 6 126 2638 C→T 107
    79 2364 C→G 107 127 2644 G→A 107
    80 2365 G→T 107 128 2645 G→A 107
    81 2367 G→A 100 129 2646 G→A 107
    G→- 7 130 2647 G→C 101
    82 2374 T→G 107 G→T 6
    83 2375 G→A 107 131 2651 C→T 107
    84 2382 C→T 107 132 2652 T→C 107
    85 2383 A→C 107 133 2672 A→G 107
    86 2386 T→G 107 134 2673 G→A 107

    Table 3.  Common Point Mutations of NTM that Are Different from E. coli Reference Sequence

    Serial Number Positions E. coli Mutant M. abscessus (n = 46) M. massiliense (n = 4) M. fortuitum (n = 9) M. avium (n = 49) M. intracellulare (n = 31) M. gordonae (n = 4)
    1 2081 T T→C - - 9 49 31 -
    2 2083 G G→A - - 9 49 31 -
    3 2099 T T→C - - 9 49 31 4
    4 2101 A A→G 46 4 - 49 31 4
    5 2131 T T→G 45 4 9 - 31 4
    T→A 1 - - - - -
    6 2136 G G→A - - - - 31 1
    7 2137 T T→C 46 4 9 49 - 4
    8 2140 G G→C - - 9 - - 4
    G→A - - - 49 31 -
    9 2141 G G→C 46 4 9 - - -
    10 2150 C C→G 46 4 9 - - -
    C→T - - - 49 31 4
    11 2151 T T→G - - 9 - - 4
    12 2152 G G→A - - - - - 4
    G→T 46 4 9 - - -
    13 2154 A A→G 46 4 9 49 - 4
    14 2162 G G→A 46 4 - - - -
    15 2164 C C→T - - 9 49 31 4
    16 2191 G G→A 46 4 - - - -
    17 2192 A A→G - - 9 - - -
    18 2196 T T→C - - - 49 31 4
    19 2202 G G→C 46 4 9 - - -
    20 2206 A A→G 46 4 9 - - -
    21 2210 G G→C - - - 49 31 -
    22 2212 - -→A 46 4 9 - - 4
    23 2215 T T→C - - - - 8 -
    24 2217 C C→G - - - 49 31 -
    25 2221 T T→C 46 4 - - - -
    26 2224 C C→G 46 4 9 - - -
    27 2238 T T→C - - - 49 31 -
    28 2267 T T→C 46 4 9 - - -
    29 2321 G G→A - - - - 31 -
    G→T 46 4 9 - - 4
    30 2322 T T→C - - - 49 31 -
    31 2328 C C→T - - 9 49 31 4
    32 2358 T T→C 41 4 - - - 1
    T→G - - 9 - - -
    33 2404 T T→C - - - 49 31 -
    34 2406 T T→C - - - 49 31 -
    35 2636 A A→G - - 9 - - -

    Table 4.  Species-specific Point Mutations in rrl Gene from 143 NTM Strains

  • While detecting 23S rRNA mutations, the presence of five types of erm genes, erm(37) to erm(41), related to mycobacteria were screened in these 143 NTM isolates. PCR amplicons of expected size (-750 bp) with erm(39) primer sets were observed in all M. fortuitum. Amplicons of the expected size (-650 bp) with erm(41) primer sets were obtained in all 46 M. abscessus subsp. abscessus isolates, while those of smaller size (-300 bp) were detected in four M. abscessus subsp. massiliense isolates. Sequencing result showed that erm(41) of M. massiliense had two deletions (nucleotides 64 and 65; 276 bp after nucleotide 158) as compared with M. abscessus and, thus, lacked most of the functional domains of ribosomal RNA adenine dimethylases. No erm gene was detected in either of the three SGM species, M. avium, M. intracellulare, or M. gordonae.

    As T/C polymorphism at 28th nucleotide on erm(41) correlated with inducible macrolide resistance[19, 20], we further compared the 3-day and 14-day antibiotic susceptibility of strains that carried erm(41) genes. Three M. abscessus subsp. abscessus strains harboring A2059G substitution were excluded, as their 3-day MICs had already reached the highest concentration. As shown in Table 5, 34 of 43 M. abscessus subsp. abscessus isolates harbored thymine at 28th nucleotide position (T28 sequevar) corresponding to Trp10 in the amino acid sequence. The other nine isolates were C28 sequevar (cytosine, Arg10). MICs of all T28 sequevar isolates reached the highest detection macrolide concentration at 14 days, irrespective of these strains being sensitive or resistant to macrolide at 3 days. In contrast, MICs of the nine C28 sequevar isolates were essentially the same at 3 and 14 days. Thus, erm gene was responsible for inducible macrolide resistance of M. abscessus subsp. abscessus; the resistance observed at 3 days was out of the interpretable range for 23S rRNA and erm gene. Although all four M. massiliense isolates were T28 sequevars, these were sensitive to macrolides and had no change in MICs upon prolongation of the antibiotic susceptibility test to 14 days owing to the deletion and loss of function of erm(41).

    M. abscessus Subspecies Sequevar Antibiotic Number of Resistant Strains (n) MIC Range (μg/mL)
    & NBSP; Day 3 Day 14 Day 3 Day 14
      M. abscessus subsp. abscessus T28 ERY 25 34 0.3-128.0 > 256.0
    (n = 34) AZM 10 34 0.3-128.0 > 256.0
    ROX 7 34 0.3-64.0 64.0-> 256.0
    CLAR 3 34 0.3-16.0 8.0-> 128.0
    C28 ERY 4 4 0.3-32.0 2.0-32.0
    (n = 9) AZM 1 1 0.3-16.0 1.0-16.0
    ROX 1 1 0.3-16.0 1.0-16.0
    CLAR 0 0 0.3-4.0 1.0-4.0
      M. abscessus subsp. massiliense T28 ERY 2 2 < 1.0-16.0 1.0-16.0
    (n = 4) AZM 0 0 < 1.0 1.0
    ROX 0 0 < 1.0 1.0
    CLAR 0 0 < 1.0 1.0

    Table 5.  Number of Resistant Strains and MIC Range at 3 and 14 Days for Two Types of erm(41) Sequevar Strains of M. abscessus subsp. abscessus and M. abscessus subsp. massiliense Absenting rrl Mutation (A2059G)

  • Pulmonary infections with NTM are becoming an increasing concern in many countries. Macrolides are one of the most important drugs used for the treatment of NTM, especially MAC infections. In the present study, the result of an in vitro antibiotic susceptibility testing confirmed the efficacy of macrolides against NTM. The resistant rates and MIC50 of all strains except M. fortuitum to AZM, ROX, and CLAR were lower than 24% and 8 μg/mL, respectively. In addition, these drugs were two- to four-fold more active than ERY in vivo[21]. CLAR was the most potent agent against NTM strains, with a resistance rate of 8.1% (25/310), and served as the only agent with high clinical efficacy in the susceptibility test[22]. These results are in line with those reported by Foo et al.[23], wherein CLAR inhibited M. abscessus and MAC at a resistance rate of 20% and 10%, respectively. AZM was administrated once daily and is beneficial for patient compliance, especially for the long-term treatment over 6 months commonly required in mycobacterial infections[24]. High efficiency of AZM against NTM was also observed. However, comparative studies with CLAR and AZM for NTM treatment are limited. In our study, AZM concentration required to inhibit NTM was higher than that of CLAR. However, some conflicting results were observed. Choi et al.[25]. found that AZM is a weaker inducer of erm(41) gene expression than CLAR and should therefore be preferred for M. abscessus infections. In contrast, the findings reported by Maurer[26] contradict this suggestion, as high median MICs of ≥ 256 μg/mL on day 12 were observed for the two drugs. Thus, further studies are warranted to determine the clinical efficacy of CLAR and AZM against NTM. The activity of ROX was reported to be comparable to that of CLAR both in vitro and in vivo in animal models[27]. Consistent with former reports, we observed a similar activity for ROX in our results. ROX was successfully used for the treatment of cutaneous M. chelonae infections[28].

    The results of the antibiotic susceptibility testing demonstrated the great difference in sensitivity between different species, particularly between M. gordonae and M. fortuitum as well as M. abscessus subsp. abscessus and M. abscessus subsp. massiliense. In our study, most of M. abscessus and M. massiliense were susceptible to macrolides on day 3. However, resistance was evident only in M. abscessus after 14 days of incubation. Truncated erm(41) was observed in M. massiliense and erm(41) polymorphism in M. abscessus was related to inducible macrolide resistance. These results support the findings that macrolide-containing regimens were more effective for the treatment of M. massiliense infections than M. abscessus[29]. In our study, 77.8% M. fortuitum were found to be resistant to CLAR and all carried erm(39). Esteban et al.[30] showed that 84.3% (75/89) M. fortuitum clinical isolates harbored erm and only 52.8% of these were resistant to CLAR. This variation may be associated with the differences in the methodology employed and regions. Thus, genetic polymorphism of erm(39) gene may exist in M. fortuitum, necessitating further studies. SGM species were more susceptible to macrolide than RGM, probably owing to the absence of erm genes in these species. We found that M. avium seemed less susceptible than M. intracellulare to macrolide, consistent with the results of previous reports[31, 32]. As macrolide susceptibility of MAC has been correlated with clinical treatment outcomes, one may expect more therapeutic failures in treating M. avium infections than M. intracellulare infections. These species-specific sensitivity suggests the importance of the identification of NTM isolates to subspecies level to design specific treatment regimens. The species-specific sites of rrl gene, such as G2321A of M. intracellulare, A2192G, T2358G, and A2636G of M. fortuitum, and G2152A of M. gordonae, identified in this study may be employed as a rapid identification method for NTM.

    The most striking observation of this study is the low detection rate of the two well-known macrolide resistance mechanisms. Several reports have suggested that point mutations at 2, 058/2, 059 position in rrl gene were the most common mechanisms to confer macrolide resistance in MAC strains and were observed in> 90% of the reported resistant mutants[22]. However, a significant fraction of resistant strains who failed to harbor any previously identified mutations were observed in former reports. In this study, the proportion of strains with 2, 058/2, 059 substitutions in 23S rRNA was particularly low and none of other substitutions related to macrolide resistance was identified. This observation was similar to M. abscessus strains isolated from Korea, wherein most strains with acquired resistance had no 2, 058/2, 059 substitutions in rrl[33]. In this study, erm(39) and erm(41) were detected in all M. fortuitum and MABC and inducible resistance was observed in relevant sequevars. However, the resistance observed at 3 days could not be explained by 23S rRNA and erm mechanisms. Therefore, the well-known macrolide resistance mechanisms failed to cover NTM isolates and meet the requirement for developing fast diagnostic methods for resistant strains to guide rational and individualized medication. The unknown mechanisms responsible for macrolide resistance in NTM remain to be elucidated.

  • LI Fu designed and performed the experiments, analyzed data, and prepared the manuscript; LI Gui Lian, PANG Hui, LIU Hai Can, XIAO Tong Yang, LI Shuang Jun, and LUO Qiao participated in the experiments; WANG Rui Bai and WAN Kang Lin designed and reviewed the draft of the manuscript. All authors read and approved the final manuscript.

  • The authors thank LI Jun Lian (Xinjian Chest Hospital, Urumqi, Xinjiang, China), WANG Qing (Anhui Chest Hospital, Hefei, Anhui Province, China), TONG Chong Xiang (Lanzhou Chest Hospital, Gansu, China), FU Jun (Nanchang Centers for Disease Control and Prevention, Jiangxi, China), YANG Jun (Sichuan Center for Disease Control and Prevention, China), and SU Yun Kai (Inner Mongolia Institute for Tuberculosis Control and Prevention, Hohhot, China) for their contributions to this study through the collection of clinical isolates.
