HAO Yan Hui, ZHAO Li, PENG Rui Yun. Effects of Electromagnetic Radiation on Autophagy and its Regulation[J]. Biomedical and Environmental Sciences, 2018, 31(1): 57-65. doi: 10.3967/bes2018.006
Citation: HAO Yan Hui, ZHAO Li, PENG Rui Yun. Effects of Electromagnetic Radiation on Autophagy and its Regulation[J]. Biomedical and Environmental Sciences, 2018, 31(1): 57-65. doi: 10.3967/bes2018.006

Effects of Electromagnetic Radiation on Autophagy and its Regulation

doi: 10.3967/bes2018.006
Funds:

the National Natural Science Foundation of China 31570847

More Information
  • Author Bio:

    HAO Yan Hui, male, born in 1990, Doctoral degree, majoring in radiation biology

    ZHAO Li, female, born in 1981, Doctoral degree and Associate research fellow, majoring in radiation biology

  • Corresponding author: PENG Rui Yun, PhD, Tel:86-10-66931236, Fax:86-10-66931336, E-mail:ruiyunpeng18@126.com
  • Received Date: 2017-06-21
  • Accepted Date: 2017-12-27
  • 加载中
  • [1] Roosli M, Rapp R, Braun-Fahrlander C. Radio and microwave frequency radiation and health——an analysis of the literature. Gesundheitswesen, 2003; 65, 378-92. doi:  10.1055/s-2003-40311
    [2] China's Ministry of Environmental Protection and the State Administration of Quality Supervision, Inspection and Quarantine. Controlling limits for electromagnetic environment (National standard of the People's Republic of China, GB 8702-2014). http://www.cssn.net.cn[2017-01-08]
    [3] World Health Organization. What is the International EMF Project? http://www.who.int/peh-emf/project/EMF_Project/en/index.html[2017-01-08]
    [4] Institute of Electrical and Electronics Engineers. IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. http://standards.ieee.org[2017-01-08]
    [5] Ms M. Thermal versus nonthermal mechanisms of interactions between electromagnetic fields and biological systems. In: Ayrapetyan SN and Markov M (eds), Bioelectromagnetics: Current Concepts. Springer, Dordrecht, the Netherlands, 2006; 1-16.
    [6] Ms M. Nonthermal mechanism of interactions between electromagnetic fields and biological systems:a calmodulin example. Environmentalist, 2011; 31, 114-20. doi:  10.1007/s10669-011-9321-1
    [7] Jauchem JR. A literature review of medical side effects from radio-frequency energy in the human environment:involving cancer, tumors, and problems of the central nervous system. J Microw Power Electromagn Energy, 2003; 38, 103-23. doi:  10.1080/08327823.2003.11688492
    [8] Erdem Koc G, Kaplan S, Altun G, et al. Neuroprotective effects of melatonin and omega-3 on hippocampal cells prenatally exposed to 900 MHz electromagnetic fields. Int J Radiat Biol, 2016; 92, 590-5. doi:  10.1080/09553002.2016.1206223
    [9] Sharma A, Kesari KK, Saxena VK, et al. Ten gigahertz microwave radiation impairs spatial memory, enzymes activity, and histopathology of developing mice brain. Mol Cell Biochem, 2017; 435, 1-13. doi:  10.1007/s11010-017-3051-8
    [10] Wang H, Peng R, Zhao L, et al. The relationship between NMDA receptors and microwave-induced learning and memory impairment:a long-term observation on Wistar rats. Int J Radiat Biol, 2015; 91, 262-9. doi:  10.3109/09553002.2014.988893
    [11] Wang H, Peng R, Zhou H, et al. Impairment of long-term potentiation induction is essential for the disruption of spatial memory after microwave exposure. Int J Radiat Biol, 2013; 89, 1100-7. doi:  10.3109/09553002.2013.817701
    [12] Wang LF, Wei L, Qiao SM, et al. Microwave-Induced Structural and Functional Injury of Hippocampal and PC12 Cells Is Accompanied by Abnormal Changes in the NMDAR-PSD95-CaMKⅡ Pathway. Pathobiology, 2015; 82, 181-94. doi:  10.1159/000398803
    [13] Xiong L, Sun CF, Zhang J, et al. Microwave exposure impairs synaptic plasticity in the rat hippocampus and PC12 cells through over-activation of the NMDA receptor signaling pathway. Biomed Environ Sci, 2015; 28, 13-24. https://www.sciencedirect.com/science/article/pii/S0895398815600022
    [14] Zhao L, Peng RY, Wang SM, et al. Relationship between cognition function and hippocampus structure after long-term microwave exposure. Biomed Environ Sci, 2012; 25, 182-8. https://www.sciencedirect.com/science/article/pii/S0895398812600427
    [15] Megha K, Deshmukh PS, Banerjee BD, et al. Low intensity microwave radiation induced oxidative stress, inflammatory response and DNA damage in rat brain. Neurotoxicology, 2015; 51, 158-65. doi:  10.1016/j.neuro.2015.10.009
    [16] Zhao L, Peng RY, Wang SM, et al. Relationship between cognition function and hippocampus structure after long-term microwave exposure. Biomed Environ Sci, 2012; 25, 182-8. https://www.sciencedirect.com/science/article/pii/S0895398812600427
    [17] Deshmukh PS, Banerjee BD, Abegaonkar MP, et al. Effect of low level microwave radiation exposure on cognitive function and oxidative stress in rats. Indian J Biochem Biophys, 2013; 50, 114-9. doi:  10.1177/1091581815574348
    [18] Valbonesi P, Franzellitti S, Bersani F, et al. Activity and expression of acetylcholinesterase in PC12 cells exposed to intermittent 1.8 GHz 217-GSM mobile phone signal. Int J Radiat Biol, 2016; 92, 1-10. doi:  10.3109/09553002.2016.1114188
    [19] Kesari KK, Siddiqui MH, Meena R, et al. Cell phone radiation exposure on brain and associated biological systems. Indian J Exp Biol, 2013; 51, 187-200.
    [20] Del Vecchio G, Giuliani A, Fernandez M, et al. Effect of radiofrequency electromagnetic field exposure on in vitro models of neurodegenerative disease. Bioelectromagnetics, 2009; 30, 564-72. doi:  10.1002/bem.v30:7
    [21] Arendash GW, Sanchez-Ramos J, Mori T, et al. Electromagnetic field treatment protects against and reverses cognitive impairment in Alzheimer's disease mice. J Alzheimers Dis, 2010; 19, 191-210. doi:  10.3233/JAD-2010-1228
    [22] Banaceur S, Banasr S, Sakly M, et al. Whole body exposure to 2.4 GHz WIFI signals:effects on cognitive impairment in adult triple transgenic mouse models of Alzheimer's disease (3xTg-AD). Behav Brain Res, 2013; 240, 197-201. doi:  10.1016/j.bbr.2012.11.021
    [23] Schuz J, Waldemar G, Olsen JH, et al. Risks for central nervous system diseases among mobile phone subscribers:a Danish retrospective cohort study. PLoS One, 2009; 4, e4389. doi:  10.1371/journal.pone.0004389
    [24] Eghlidospour M, Ghanbari A, Mortazavi SMJ, et al. Effects of radiofrequency exposure emitted from a GSM mobile phone on proliferation, differentiation, and apoptosis of neural stem cells. Anat Cell Biol, 2017; 50, 115-23. doi:  10.5115/acb.2017.50.2.115
    [25] Tamrin SH, Majedi FS, Tondar M, et al. Electromagnetic Fields and Stem Cell Fate:When Physics Meets Biology. Rev Physiol Biochem Pharmacol, 2016; 171, 63-97. doi:  10.1007/978-3-319-43814-6
    [26] Maziarz A, Kocan B, Bester M, et al. How electromagnetic fields can influence adult stem cells:positive and negative impacts. Stem Cell Res Ther, 2016; 7, 54. doi:  10.1186/s13287-016-0312-5
    [27] Maioli M, Rinaldi S, Santaniello S, et al. Radio electric conveyed fields directly reprogram human dermal skin fibroblasts toward cardiac, neuronal, and skeletal muscle-like lineages. Cell Transplant, 2013; 22, 1227-35. doi:  10.3727/096368912X657297
    [28] Huber LA, Teis D. Lysosomal signaling in control of degradation pathways. Curr Opin Cell Biol, 2016; 39, 8-14. doi:  10.1016/j.ceb.2016.01.006
    [29] Ravikumar B, Sarkar S, Davies JE, et al. Regulation of mammalian autophagy in physiology and pathophysiology. Physiol Rev, 2010; 90, 1383-435. doi:  10.1152/physrev.00030.2009
    [30] Kaushik S, Bandyopadhyay U, Sridhar S, et al. Chaperone-mediated autophagy at a glance. J Cell Sci, 2011; 124, 495-9. doi:  10.1242/jcs.073874
    [31] Mizushima N, Yoshimori T, Ohsumi Y. The role of Atg proteins in autophagosome formation. Annu Rev Cell Dev Biol, 2011; 27, 107-32. doi:  10.1146/annurev-cellbio-092910-154005
    [32] Lin MG, Hurley JH. Structure and function of the ULK1 complex in autophagy. Curr Opin Cell Biol, 2016; 39, 61-8. doi:  10.1016/j.ceb.2016.02.010
    [33] Itakura E, Mizushima N. Characterization of autophagosome formation site by a hierarchical analysis of mammalian Atg proteins. Autophagy, 2010; 6, 764-76. doi:  10.4161/auto.6.6.12709
    [34] Russell RC, Tian Y, Yuan H, et al. ULK1 induces autophagy by phosphorylating Beclin-1 and activating VPS34 lipid kinase. Nat Cell Biol, 2013; 15, 741-50. doi:  10.1038/ncb2757
    [35] Pankiv S, Clausen TH, Lamark T, et al. p62/SQSTM1 binds directly to Atg8/LC3 to facilitate degradation of ubiquitinated protein aggregates by autophagy. J Biol Chem, 2007; 282, 24131-45. doi:  10.1074/jbc.M702824200
    [36] Lim J, Lachenmayer ML, Wu S, et al. Proteotoxic stress induces phosphorylation of p62/SQSTM1 by ULK1 to regulate selective autophagic clearance of protein aggregates. PLoS Genet, 2015; 11, e1004987. doi:  10.1371/journal.pgen.1004987
    [37] Mcalpine F, Williamson LE, Tooze SA, et al. Regulation of nutrient-sensitive autophagy by uncoordinated 51-like kinases 1 and 2. Autophagy, 2013; 9, 361-73. doi:  10.4161/auto.23066
    [38] Petherick KJ, Conway OJ, Mpamhanga C, et al. Pharmacological inhibition of ULK1 kinase blocks mammalian target of rapamycin (mTOR)-dependent autophagy. J Biol Chem, 2015; 290, 11376-83. doi:  10.1074/jbc.C114.627778
    [39] Lazarus MB, Shokat KM. Discovery and structure of a new inhibitor scaffold of the autophagy initiating kinase ULK1. Bioorg Med Chem, 2015; 23, 5483-8. doi:  10.1016/j.bmc.2015.07.034
    [40] Burman C, Ktistakis NT. Regulation of autophagy by phosphatidylinositol 3-phosphate. FEBS Lett, 2010; 584, 1302-12. doi:  10.1016/j.febslet.2010.01.011
    [41] Kroemer G, Marino G, Levine B. Autophagy and the integrated stress response. Mol Cell, 2010; 40, 280-93. doi:  10.1016/j.molcel.2010.09.023
    [42] Mizushima N, Kuma A, Kobayashi Y, et al. Mouse Apg16L, a novel WD-repeat protein, targets to the autophagic isolation membrane with the Apg12-Apg5 conjugate. J Cell Sci, 2003; 116, 1679-88. doi:  10.1242/jcs.00381
    [43] Mizushima N, Yamamoto A, Hatano M, et al. Dissection of autophagosome formation using Apg5-deficient mouse embryonic stem cells. J Cell Biol, 2001; 152, 657-68. doi:  10.1083/jcb.152.4.657
    [44] Sou YS, Waguri S, Iwata J, et al. The Atg8 conjugation system is indispensable for proper development of autophagic isolation membranes in mice. Mol Biol Cell, 2008; 19, 4762-75. doi:  10.1091/mbc.E08-03-0309
    [45] Geng J, Klionsky DJ. The Atg8 and Atg12 ubiquitin-like conjugation systems in macroautophagy. 'Protein modifications:beyond the usual suspects' review series. EMBO Rep, 2008; 9, 859-64. doi:  10.1038/embor.2008.163
    [46] Otomo C, Metlagel Z, Takaesu G, et al. Structure of the human ATG12~ATG5 conjugate required for LC3 lipidation in autophagy. Nat Struct Mol Biol, 2013; 20, 59-66. doi:  10.1038/nsmb.2431
    [47] Young AR, Chan EY, Hu XW, et al. Starvation and ULK1-dependent cycling of mammalian Atg9 between the TGN and endosomes. J Cell Sci, 2006; 119, 3888-900. doi:  10.1242/jcs.03172
    [48] Orsi A, Razi M, Dooley HC, et al. Dynamic and transient interactions of Atg9 with autophagosomes, but not membrane integration, are required for autophagy. Mol Biol Cell, 2012; 23, 1860-73. doi:  10.1091/mbc.E11-09-0746
    [49] Pasi F, Fassina L, Mognaschi ME, et al. Pulsed Electromagnetic Field with Temozolomide Can Elicit an Epigenetic Pro-apoptotic Effect on Glioblastoma T98G Cells. Anticancer Res, 2016; 36, 5821-6. doi:  10.21873/anticanres
    [50] Jiang DP, Li JH, Zhang J, et al. Long-term electromagnetic pulse exposure induces Abeta deposition and cognitive dysfunction through oxidative stress and overexpression of APP and BACE1. Brain Res, 2016; 1642, 10-9. doi:  10.1016/j.brainres.2016.02.053
    [51] Marchesi N, Osera C, Fassina L, et al. Autophagy is modulated in human neuroblastoma cells through direct exposition to low frequency electromagnetic fields. J Cell Physiol, 2014; 229, 1776-86. doi:  10.1002/jcp.24631
    [52] Liu K, Zhang G, Wang Z, et al. The protective effect of autophagy on mouse spermatocyte derived cells exposure to 1800MHz radiofrequency electromagnetic radiation. Toxicol Lett, 2014; 228, 216-24. doi:  10.1016/j.toxlet.2014.05.004
    [53] Koshkina NV, Briggs K, Palalon F, et al. Autophagy and enhanced chemosensitivity in experimental pancreatic cancers induced by noninvasive radiofrequency field treatment. Cancer, 2014; 120, 480-91. doi:  10.1002/cncr.28453
    [54] Curley SA, Palalon F, Sanders KE, et al. The effects of non-invasive radiofrequency treatment and hyperthermia on malignant and nonmalignant cells. Int J Environ Res Public Health, 2014; 11, 9142-53. doi:  10.3390/ijerph110909142
    [55] Curley SA, Palalon F, Lu X, et al. Noninvasive radiofrequency treatment effect on mitochondria in pancreatic cancer cells. Cancer, 2014; 120, 3418-25. doi:  10.1002/cncr.28895
    [56] Cao H, Xu Z, Liu X, et al. Effect of autophagy on lung cancer cell line A549 by microwave radiation non-thermal effect. J Pract Oncol, 2012; 27, 271-3.
    [57] Zuo WQ, Hu YJ, Yang Y, et al. Sensitivity of spiral ganglion neurons to damage caused by mobile phone electromagnetic radiation will increase in lipopolysaccharide-induced inflammation in vitro model. J Neuroinflammation, 2015; 12, 105. doi:  10.1186/s12974-015-0300-1
    [58] Golbach LA, Scheer MH, Cuppen JJ, et al. Low-Frequency Electromagnetic Field Exposure Enhances Extracellular Trap Formation by Human Neutrophils through the NADPH Pathway. J Innate Immun, 2015; 7, 459-65. doi:  10.1159/000380764
    [59] Tan S, Wang H, Xu X, et al. Study on dose-dependent, frequency-dependent, and accumulative effects of 1.5 GHz and 2.856 GHz microwave on cognitive functions in Wistar rats. Sci Rep, 2017; 7, 10781. doi:  10.1038/s41598-017-11420-9
    [60] Nguyen THP, Pham VTH, Baulin V, et al. The effect of a high frequency electromagnetic field in the microwave range on red blood cells. Sci Rep, 2017; 7, 10798. doi:  10.1038/s41598-017-11288-9
    [61] Li L, Zhang Q, Tan J, et al. Autophagy and hippocampal neuronal injury. Sleep Breath, 2014; 18, 243-9. doi:  10.1007/s11325-013-0930-4
    [62] Gozuacik D, Akkoc Y, Ozturk DG, et al. Autophagy-Regulating microRNAs and Cancer. Front Oncol, 2017; 7, 65. doi:  10.3389/fonc.2017.00065/full
    [63] Shahin S, Singh VP, Shukla RK, et al. 2.45 GHz microwave irradiation-induced oxidative stress affects implantation or pregnancy in mice, Mus musculus. Appl Biochem Biotechnol, 2013; 169, 1727-51. doi:  10.1007/s12010-012-0079-9
    [64] Campisi A, Gulino M, Acquaviva R, et al. Reactive oxygen species levels and DNA fragmentation on astrocytes in primary culture after acute exposure to low intensity microwave electromagnetic field. Neurosci Lett, 2010; 473, 52-5. doi:  10.1016/j.neulet.2010.02.018
    [65] Sokolovic D, Djindjic B, Nikolic J, et al. Melatonin reduces oxidative stress induced by chronic exposure of microwave radiation from mobile phones in rat brain. J Radiat Res, 2008; 49, 579-86. doi:  10.1269/jrr.07077
    [66] Ammari M, Lecomte A, Sakly M, et al. Exposure to GSM 900 MHz electromagnetic fields affects cerebral cytochrome c oxidase activity. Toxicology, 2008; 250, 70-4. doi:  10.1016/j.tox.2008.05.019
    [67] Friedman J, Kraus S, Hauptman Y, et al. Mechanism of short-term ERK activation by electromagnetic fields at mobile phone frequencies. Biochem J, 2007; 405, 559-68. doi:  10.1042/BJ20061653
    [68] Johnson GL, Lapadat R. Mitogen-activated protein kinase pathways mediated by ERK, JNK, and p38 protein kinases. Science, 2002; 298, 1911-2. doi:  10.1126/science.1072682
    [69] Maher P, Schubert D. Signaling by reactive oxygen species in the nervous system. CMLS, 2000; 57, 1287-305. doi:  10.1007/PL00000766
    [70] Li L, Tan J, Miao Y, et al. ROS and Autophagy:Interactions and Molecular Regulatory Mechanisms. Cell Mol Neurobiol, 2015; 35, 615-21. doi:  10.1007/s10571-015-0166-x
    [71] Bader AG, Brown D, Stoudemire J, et al. Developing therapeutic microRNAs for cancer. Gene Ther, 2011; 18, 1121-6. doi:  10.1038/gt.2011.79
    [72] Lanford RE, Hildebrandt-Eriksen ES, Petri A, et al. Therapeutic silencing of microRNA-122 in primates with chronic hepatitis C virus infection. Science, 2010; 327, 198-201. doi:  10.1126/science.1178178
    [73] Zhao L, Sun C, Xiong L, et al. MicroRNAs:Novel Mechanism Involved in the Pathogenesis of Microwave Exposure on Rats' Hippocampus. J Mol Neurosci, 2014; 53, 222-30. doi:  10.1007/s12031-014-0289-4
    [74] Wang P, Liang J, Li Y, et al. Down-regulation of miRNA-30a alleviates cerebral ischemic injury through enhancing beclin 1-mediated autophagy. Neurochem Res, 2014; 39, 1279-91. doi:  10.1007/s11064-014-1310-6
    [75] Yang X, Bai F, Xu Y, et al. Intensified Beclin-1 Mediated by Low Expression of Mir-30a-5p Promotes Chemoresistance in Human Small Cell Lung Cancer. Cell Physiol Biochem, 2017; 43, 1126-39. doi:  10.1159/000481754
    [76] Guo D, Ma J, Yan L, et al. Down-Regulation of Lncrna MALAT1 Attenuates Neuronal Cell Death Through Suppressing Beclin1-Dependent Autophagy by Regulating Mir-30a in Cerebral Ischemic Stroke. Cell Physiol Biochem, 2017; 43, 182-94. doi:  10.1159/000480337
    [77] Chen J, Yu Y, Li S, et al. MicroRNA-30a ameliorates hepatic fibrosis by inhibiting Beclin1-mediated autophagy. J Cell Mol Med, 2017; 21, 3679-92. doi:  10.1111/jcmm.2017.21.issue-12
    [78] Xu R, Liu S, Chen H, et al. MicroRNA-30a downregulation contributes to chemoresistance of osteosarcoma cells through activating Beclin-1-mediated autophagy. Oncol Rep, 2016; 35, 1757-63. doi:  10.3892/or.2015.4497
    [79] Yang Y, Li Y, Chen X, et al. Exosomal transfer of miR-30a between cardiomyocytes regulates autophagy after hypoxia. J Mol Med (Berl), 2016; 94, 711-24. doi:  10.1007/s00109-016-1387-2
    [80] Zhu H, Wu H, Liu X, et al. Regulation of autophagy by a beclin 1-targeted microRNA, miR-30a, in cancer cells. Autophagy, 2009; 5, 816-23. doi:  10.4161/auto.9064
  • 加载中
通讯作者: 陈斌, bchen63@163.com
  • 1.

    沈阳化工大学材料科学与工程学院 沈阳 110142

  1. 本站搜索
  2. 百度学术搜索
  3. 万方数据库搜索
  4. CNKI搜索

Tables(1)

Article Metrics

Article views(1266) PDF downloads(89) Cited by()

Proportional views
Related

Effects of Electromagnetic Radiation on Autophagy and its Regulation

doi: 10.3967/bes2018.006
Funds:

the National Natural Science Foundation of China 31570847

  • Author Bio:

  • Corresponding author: PENG Rui Yun, PhD, Tel:86-10-66931236, Fax:86-10-66931336, E-mail:ruiyunpeng18@126.com
HAO Yan Hui, ZHAO Li, PENG Rui Yun. Effects of Electromagnetic Radiation on Autophagy and its Regulation[J]. Biomedical and Environmental Sciences, 2018, 31(1): 57-65. doi: 10.3967/bes2018.006
Citation: HAO Yan Hui, ZHAO Li, PENG Rui Yun. Effects of Electromagnetic Radiation on Autophagy and its Regulation[J]. Biomedical and Environmental Sciences, 2018, 31(1): 57-65. doi: 10.3967/bes2018.006
  • With the ever increasing application of electronic technology, our exposure to artificial electromagnetic energy is also rapidly increasing. Electromagnetic radiation (EMR) is the fourth largest source of pollution, after air, water, and noise[1]. All populations are now exposed to varying degrees of EMR, and this poses a serious public health threat. The human level of exposure to EMR will continue to increase as technology advances and becomes an integral part of our day to day lives. EMR pollution has attracted widespread concern. Ashford and Porter (1962) discovered the phenomenon of 'self-eating' in the rat liver cells for the first time, which de Duve (1963) christened as 'autophagy.' There is strong interest in the field of biomedicine for pursuing research on cell autophagy. Autophagy is widely involved in many physiological and pathological processes, which is important for regulating cell function and maintaining cell homeostasis. It has been recognized that autophagy functions in the cell damage caused by EMR.

  • EMR is defined as waves of oscillating electric and magnetic fields that move at right angles to each other and outward from both the electric (E) and magnetic (B) oscillating field vectors, and is essentially non-ionizing radiation, as it does not carry enough energy to ionize atoms or molecules. The 'Controlling limits for electromagnetic environment' (GB 8702-2014) jointly issued by China's Ministry of Environmental Protection and the State Administration of Quality Supervision, Inspection and Quarantine was implemented on January 1, 2015, and there are corresponding provisions on the scope of exemption on the limit values, evaluation methods and related facilities (equipment) of electric, magnetic and electromagnetic fields (1 Hz to 300 GHz)[2]. The World Health Organization (WHO) established the International Electromagnetic Fields Project in 1996 to assess the scientific evidence of possible health and environmental effects of electromagnetic fields (EMF) in a frequency ranging from 0 Hz to 300 GHz[3]. The EMR discussed in this review has a frequency ranging from 0 Hz to 300 GHz, to which everyone in the world is exposed daily and has a great impact on our everyday life.

    EMR of different frequency bands have different physical characteristics with different applications in various fields. This range (0 Hz to 300 GHz) is divided into static (0 Hz) field, which comes primarily from natural and man-made sources such as video displays, clinical diagnostic equipments like MRI and others, that are used in medical diagnostics and treatment as well as magnetic levitation technology or maglev that is being widely used in many applications. Extremely low frequency (ELF > 0 Hz to 300 kHz) fields, which come mainly from the power transmission and electrical equipments and intermediate frequency (IF > 300 Hz to 10 MHz) fields, which includes longwaves, medium waves, and partial shortwaves that are mainly derived from the radio system[3]; Radiofrequency (RF 100 kHz to 300 GHz) fields, which are applied in various facets of daily life, such as telecommunications (eg., mobile telephones), radio and TV transmission, diagnosis and treatments of disease, and in industry for heating and sealing materials[4]. Additionally, RF fields with frequencies ranging from 10 MHz to 30 MHz are called shortwaves, that are mainly used in radio broadcast and over-the-horizon (OTH) radar, while fields with frequencies from 300 MHz to 300 GHz are called microwaves (MW), which are mostly applied in radar and communications technology. Extremely high frequencies (EHF) fields from 100 GHz to 300 GHz are used in weapons systems, security screening, and medicine. Very little is known about the terahertz (THz) band (0.1 THz to 3 THz).

  • The biological effects of EMR change with frequency, intensity, modulation mode and duration of exposure and cell microenvironment. Generally, the possible mechanisms of interactions of EMR with biological systems are often discussed in bioelectromagnetics in terms of thermal versus non-thermal mechanisms. The reported effects of EMR on tissues and organs are generally attributable to the thermal effects, whereas the non-thermal effects of EMR are still been actively researched. The thermal mechanisms are thought to play an important role in acute, high dose exposure causing toxicities. Meanwhile, there is a whole series of biologically important modifications appearing under weak static or alternating EMF action that could be explained only from the view point of non-thermal mechanisms. The thermal and non-thermal characteristics of interactions between EMR and living systems have been discussed elsewhere[5-6].

    Multiple systems of the organisms are subjected to the impact of EMR, but the nervous, reproductive, cardiovascular, immune, hematopoietic, and endocrine systems are most commonly involved; thereby, they are extensively studied. Taking the central nervous system and stem cells as an example, we discuss the biological effects of EMR at the overall system and the cellular level, respectively. (1) The central nervous system. The brain is one of the target organs that are sensitive to EMR because the mitochondrial injury occurs here earlier and is more severe as compared to other tissues and organ systems in body. The mitochondrial injury disrupts the energy metabolism in brain and leads to brain dysfunction and structural brain damage because of depleted ATP stores. Epidemiological survey finds that EMR causes fatigue, headache, excitement, dreams, memory loss, and other symptoms of neurasthenia[7]. The studies conducted by us and other researchers have indicated that EMR is likely to cause brain dysfunction and synaptic plasticity injury, as mainly seen in cognitive impairment and structural damage[8-17]. Additionally, EMR has been reported to contribute to neurodegenerative diseases, such as Alzheimer's disease (AD) because of disruption of the signaling pathway[18-20]. In contrast, there is increasing evidence that EMR may help stimulate neuronal functions and protect against cognitive impairment in diseases, such as AD[21-23]. Although, the majority of data comes from animal studies that cannot be yet extrapolated to humans. (2) Stem cells reside in almost all tissues within the human body, and they exhibit various potentials. These cells are very important because they control homeostasis, regeneration, and healing. On one side, accumulating dose of EMR is thought to have devastating effects on stem cell proliferation[24], and on the other side, studies have demonstrated that EMR is able to regulate cellular processes related to decisions about the fate of stem cell via different ways, and properly adjusted values of EMR frequencies, times of stimulation as well as the microenvironmental niche may affect the impact of EMR on stem cell proliferation, differentiation, and migration to achieve the desired therapeutic outcomes[25-27].

    The potential health hazards induced by EMR radiation are not negligible, and the public is not completely aware of potential dangers for human health deriving from EMR pollution and exposure to low radiation. Looking at the other side of the coin, EMR has found a wide range of potential clinical applications, as demonstrated by studies reporting the protective effects of EMR on AD and the ability of EMR to decide stem cell fate. Therefore, the underlying mechanisms that decide the biological effects of EMR are important and a controlled use of EMR may be useful for therapeutic purposes.

  • Autophagy is an evolutionarily highly conserved, lysosome-dependent cellular recycling pathway existing in eukaryotic cells that transports cytoplasmic components, such as misfolded proteins and damaged organelles to lysosomes for degradation and eventually recycling of the degraded products. Autophagy plays a critical role in cell adaptation, clearance of intra-cellular organisms, antiaging, and tumor suppression. It is mediated through unique cell organelle called autophagosome. There are three main forms of autophagy: macroautophagy, microautophagy and chaperone-mediated autophagy (CMA), which differ based on the pathways of the substrates into the lysosomes[28]. During macroautophagy, cytoplasmic proteins or organelles are wrapped in double-membrane autophagosomes, which then fuse with lysosomes to form autolysosomes. In autolysosomes, the wrapped material is degraded by lysosomal hydrolases and the degradation products are recycled by cells[29]. Unlike macroautophagy, the cytoplasmic components are directly absorbed through the invagination, protrusion, and septation of the lysosomal membrane in microautophagy and no intermediate vesicles are necessary. In contrast, CMA targets the cytoplasmic proteins with special sequence motifs recognized by heat shock cognate protein 70 (Hsc70), which is a cytosolic chaperone protein, and participates in many other cellular functions. Through the recognition of Hsc70 by lysosomal associated membrane protein 2A (LAMP-2A), which is a receptor on the lysosome surface, Hsc70-tagged proteins are captured by lysosomes, where the protein substrate is unfolded and translocated inside lysosomes for degradation[30]. Yeast and mammalian cells are commonly used as models in the autophagy research, and in many cases, the two are described together. In this paper, the autophagy we discussed focuses on mammalian macroautophagy, which is referred to as 'autophagy' herein.

  • Autophagy is a dynamic process that changes over time and is usually divided into the following four typical stages: (1) First stage involves induction, nucleation, and the formation of phagophores. After the process of autophagy is induced, proteins and lipids are recruited to form a bilayer membranous cup-like structure around the substrates to be degraded in the cytoplasm. This is called as pre-autophagosome structure (PAS) that then develops to form a phagophore, which is also known as an isolation membrane (IM). (2) Second stage involves complete elongation and sequestration of the expanding phagophore to form double-membraned organelle called as autophagosomes. (3) Third stage involves transfer of autophagosome and their fusion with the lysosomes compartment. Once autophagosome formation is complete, autophagosomes move along microtubules in a dynein motor-dependent manner and cluster close to the microtubule-organizing center near the nucleus, where they fuse with lysosomes. It has been proposed that autophagosomes first fuse with endosomes to form amphisomes, before fusion with lysosome. Subsequently, the inner vesicles are released into lysosomes, which results in the formation of monolayer autolysosomes. (4) Fourth stage involves degradation, recycling and reuse of the degraded material. After the formation of autolysosomes, the hydrolytic enzymes in the lysosomes are activated to degrade the contents of the vesicles and the amino acids, nucleotides and metabolites produced are reused by cells. In addition, the contents of the autophagic structure and lysosomes are also partially retrieved.

  • The genes involved in autophagy regulation are named as autophagy-related genes (ATG) and are a family of genes that are evolutionarily conserved. More than 30 ATG genes have been identified, and these genes are divided into different functional groups and play different roles in different stages of autophagy[31].

    ULK1 complex plays a central role in inducing autophagy, by initiating the autophagosome formation. Mammalian ULK1 (unc-51-like activating kinase 1) complex contains the core proteins ULK1 or ULK2 (hereafter we only refer to ULK1), ATG (autophagy-related protein) 13, ATG101 and focal adhesion kinase interacting protein of 200 kD (FIP200), which is stable and required for the induction of autophagosome formation[32]. After activation of the ULK1 complex, it is transferred from the cytoplasm to the endoplasmic reticulum or other specific locations to form the autophagic prokaryotic nucleus, which then raises the downstream phosohatidylinositol-3-kinase catalytic subunit type 3 (PI3KC3) complex and microtubule-associated protein light chain 3 (MAP/LC3 or LC3) molecules to produce phagophores[33]. ULK1 activates the PI3KC3 complex and promotes autophagy, through phosphorylation of Ser14 in Beclin1[34]. Polyubiquitin-binding protein (p62) also known as sequestosome 1 (SQSTM1), is required both for the formation and the degradation of polyubiquitin-containing bodies by autophagy[35]. ULK1 enhances the binding affinity of p62 for ubiquitin through phosphorylating its corresponding sites[36]. Inhibition of ULK1/2 by knockout or drugs (such as MRT67307 etc.) blocks the occurrence of autophagy[37-39].

    The PI3KC3 complex is necessary in the nucleation of the phagophore. The PI3KC3 complex contains the core proteins PI3KC3, p150, Beclin1, and ATG14. One of the key functions of the PI3K complex is the generation of phosphatidylinositol-3-phosphate (PI3P), which is a phosphoinositide that serves as a landmark on the membrane to recruit other factors, such as WD-repeat protein interacting with phosphoinositidesI1-4 (WIPI1-4) and double FYVE domain-containing protein 1 (DFCP1), which mark sites of autophagosome formation and lead to omegasome/cradle development[40-41]. The inhibition of PI3KC3 complex, by the common specific inhibitor of autophagic/lysosomal degradation 3-methyladenine (3-MA), wortmannin, and LY294002, etc., suppresses the autophagic activity.

    After nucleation, the phagophore expands by membrane addition, which is accomplished by two ubiquitylation-like conjugation systems: the ATG12-ATG5-ATG16 and ATG8 (MAP1LC3, or briefly LC3 in mammals) conjugation systems[31, 42-46], and the ATG8 conjugation system. The ATG12-ATG5-ATG16 conjugation system contains the core proteins ATG5, ATG12, ATG7, ATG10, ATG16, and autophagy related-like 1 (ATG16L1). The ATG8 conjugation system contains the core proteins LC3, ATG3, ATG4, and ATG7. The first of these systems covalently conjugates ATG12 to ATG5 by ATG10 (E2-like), whereas the second system conjugates LC3 to phosphatidylethanolamine (PE) by ATG3 (E2-like) after LC3 has been processed by the cysteine protease ATG4. Both the ATG8 and ATG12 proteins are activated by ATG7 (E1-like). The ATG12-ATG5 conjugate forms a complex with ATG16, which in turn promotes LC3-PE conjugation in an E3-like manner, although it is not essential for this process to occur.

    ATG9L1 contributes to vesicle retrieval. ATG9L1, which is a multi-spanning transmembrane protein, is localized to preautophagosomal structure (PAS), endosomes and the trans-Golgi network[47]. As a carrier of lipids, or as a platform responsible for raising other autophagy-related proteins to PAS, ATG9L1 is necessary for the formation of autophagic membranes and the recycling of some proteins[48].

  • Research on the effects of EMR on autophagy belongs to a relatively new field, and a consensus has yet not been reached. There have been conflicting reports on the role of EMR in inducing autophagy. Most studies are in support of EMR being positively involved in activating autophagy[49-56], while a few others suggest that there were no observed effects of EMR on autophagy[54, 57-58]. Different laboratories have reached different conclusions, which may be explainable by the different parameters of EMR and different objectives of the experiments in the research methods. (Table 1).

    Year Author Parameters Duration Thermal Effect Objects Autophagy State
    2016 Pasi F et al. [49] 2 mT, 75 Hz Not clear Not clear Human glioblastoma cell line (T98G) Activated
    2016 Jiang DP et al.[50] Repetition frequency 100 Hz, 50 kV/m, 100 to 100, 000 pulses Daily exposure for 8 months since 2-month-old Not mentioned SD rats, hippocampus Activated
    2014 Marchesi N et al.[51] 75 Hz, 5 mV, 1.3 ms, 2 mT 1 h Not mentioned SH-SY5Y Activated
    2014 Liu K et al. [52] 1800 MHz, 4 W/kg 24 h, 5 min on and 10 min off Rise of approximately 0.08 ℃ Mouse spermatocyte-derived GC-2 cells Activated
    2014 Koshkina NV et al.[53] 13.56 MHz, 600 to 900 W 2-5 min Not mentioned Panc-1 and AsPC-1 Activated
    2014 Curley SA et al.[54, 55] 13.56 MHz, 900 W 5 min Elevation to approximately 46 ℃ Panc-1, AsPC-1, MDA PATC-3 Activated
    2012 Cao HL et al. [56] 12, 18, and 21 mV/cm2 10 min None A549 cells Activated
    2015 Zuo WQ et al.[57] 1800 MHz, 4 W/kg 24 h, 5 min on and 10 min off Rise by about 0.08 ℃ Spiral ganglion neurons (SGN) Unchanged
    2015 Golbach LA et al.[58] 320, 730, 880, and 2600 Hz, 300 μT 4 h Not mentioned Human neutrophils Unchanged
    2014 Curley SA et al.[54] 13.56 MHz, 900 W 5 min Elevation to approximately 46 ℃ HPDE cells Unchanged

    Table 1.  Effects of EMR on Autophagy

    The effects of EMR on autophagy are mainly achieved through its non-thermal effects. Curley SA et al.[54] exposed three human pancreatic cancer cell lines (Panc-1, MDA PATC-3, and AsPC-1) to the RF field at 13.56 MHz for 5 min or to conventional hyperthermia (HT) at 46 ℃. RF treatment affected mitochondrial function in cancer cells more than HT treatment did, and unlike HT treatment, it was followed by an increase in autophagosomes in the cytoplasm of the cancer cells, and subsequent growth arrest of the cancer cells. The obtained data indicated that the effects of RF treatment were not limited to its hyperthermic property. Cao HL et al.[56] exposed human lung cancer A549 cells to the MW source for 10 min under ice bath conditions at doses of 12, 18, and 21 mV/cm2, respectively. It was found that the non-thermal effects of MW could induce autophagy in human A549 cells, while no change in temperature occurred before and after radiation, as confirmed by a thermometer. Some researchers have been supportive of the idea that the non-thermal mechanisms contribute to the biological effects of EMR, especially wide band EMR. This conclusion is also supported by results of studies that show that the temperature was precisely controlled[54, 59-60]. Therefore, we believe that the enhanced autophagy induced by EMR is likely achieved through its non-thermal characteristics, rather than the thermal characteristics.

    The effects of EMR on autophagy are related to cell types. In the study of Curley SA et al., malignant and nonmalignant cells of pancreatic origin were both exposed to the RF field with same radiation intensity. RF treatment selectively inhibited the proliferation of tumor cells by inducing autophagy, while these effects were negligible in nonmalignant cells. The results indicate RF can provide a non-invasive treatment option to treat malignancies due to its tumor-specific cytotoxic effect through stimulation of autophagy in tumor cells. These effects exceed the hyperthermic properties of the RF field. All these outcomes require further investigation of the biological effects of RF treatment to stimulate the development of novel non-invasive approaches for cancer treatment using electromagnetic fields[54].

    The effects of EMR on autophagy are also affected by cellular microenvironment. Spiral ganglion neurons (SGN), which were obtained from neonatal (1-to 3-day-old) Sprague Dawley® (SD) rats, were treated with lipopolysaccharide (LPS) and then exposed to radiofrequency EMR (RF-EMR) at a specific absorption rate (SAR) of 4 W/kg. It seems that the occurrence of autophagy caused by EMR will increase in an LPS-induced inflammation in vitro model, while it did not have any effect on normal SGN not treated with LPS[57]. The sensitivity of cell autophagy to EMR changes with the microenvironment of the cells possibly. LPS, exemplified in this study, is also a known endotoxin and is often released by gram-negative bacteria that infect the body and increases the sensitivity of EMR exposed cells to autophagy. Other factors that can alter the cellular microenvironment may also cause changes in the sensitivity of autophagy to EMR, but further studies are still needed.

    The effects of EMR on autophagy occur in a dose-dependent manner. Liu K et al.[52] exposed mouse spermatocyte-derived GC-2 cells to 1800 MHz Global System for Mobile Communication (GSM) signals in GSM-Talk mode at SAR values of 1 W/kg, 2 W/kg or 4 W/kg for 24 h intermittently. The results indicated that the activity of autophagy increased in a dose-dependent manner with RF exposure and peaked at the SAR value of 4 W/kg. In the study of Cao HL et al., within the dose ranging from 12 to 21 mV/cm2, the activation of autophagy in A549 cells was also significantly enhanced in the exposed group with the increase of the radiation dose[56]. The results point to that the effects of EMR on cell autophagy obey a dose-response relationship, and to be specific, autophagy is more active with increasing doses of EMR under certain conditions.

    The effects of EMR on autophagy obey a time-response relationship. In the study by Liu K et al. to study the protective effect of autophagy on mouse spermatocyte exposed to EMR, the LC3-Ⅱ flux increased within 48 h after exposure, which indicates the increased activity of autophagy in this time range[52]. The time-response manner in the rate of autophagy induced by EMR may be affected by the exposed objects and the radiation conditions. To find out how autophagy alters after EMR is conducive in explaining the physiological roles played by autophagy in the effects of EMR.

    In summary, the effects of EMR on autophagy are mainly achieved through non-thermal mechanisms, and these effects are affected by the cell types, as well as the cellular microenvironment and they follow dose-dependent and time-response patterns. However, the research field is still in its early stage, and there is a need for further studies and discussion.

  • The biological effects of autophagy function in two ways. For decades, autophagy has been debated as an active cell death pathway. Autophagy was usually observed in dying and starving cells, and is also known as autopathic cell death (ACD) or type Ⅱ programmed cell death that occurs without chromatin condensation and is accompanied by large-scale autophagic vacuolization of the cytoplasm. In addition, there were studies that uncontrolled autophagy was shown to lead to a caspase-dependent and independent cell death under some conditions. However, more recent data support that autophagy exerts a cryoprotective effect and promoted cell survival. One of the key roles played by autophagy is to eliminate protein aggregates and damaged organelles, which may promote energy homeostasis or reduce the generation of reactive oxygen species (ROS) in different cases[61-62].

    When cells were damaged by EMR and the injury could be compensated, activated autophagy functioned to protect cells and promote their survival. As mentioned before, in the study of Liu K et al., GC-2 cells were subjected to GSM signals at SAR values of 4 W/kg for 24 h. To understand the role of ROS-mediated autophagy on cell survival after RF exposure, 3-MA was used to block autophagy and then apoptosis was determined. Compared to RF exposure alone, co-treatment with 3-MA increased the percentage of apoptotic cells. These data indicated that autophagy may play an important role in the adaptive response mechanism to protect against EMR and ensure cell survival[52].

    When the EMR-induced damage was beyond the compensatory ability of cells, autophagy might be excessively activated and mediate cell death. Curley SA et al.[54] exposed cancer and nonmalignant cells of pancreatic origin to the RF with the average power of 900 W, for 5 min. Only RF treatment caused declines in cancer cell viability and proliferation alone with the elevation of autophagosomes in the cytoplasm of cancer cells, whereas the effects of RF treatment were negligible in nonmalignant cells. The results indicated that autophagy activation played a role in the decrease of the activity of pancreatic cancer cells induced by EMR. However, this study did not set up an autophagy intervention model and further explored the relationship between the activation of autophagy and the changes of tumor cell viability after radiation. Therefore, the numbers were not conclusive.

  • ROS includes oxygen free radicals, such as superoxide anion radical (O2·−), hydroxyl radical (·OH), and nonradical oxidants, such as hydrogen peroxide (H2O2) and singlet oxygen (1O2). Under physiological condition the balance between ROS production and its scavenging is strictly controlled and plays a part in cell homeostasis. EMR causes increased production of ROS, which in turn damages the mitochondrial respiratory chain resulting in electronic leakage (the main source of ROS) that ultimately leads to a vicious cycle[63-67]. Additionally, oxidative modification and increased ROS bring about dysfunction of cellular physiology, such as the activation or suppression of multiple signal paths, which is believed mostly to contribute to cell damage[68, 69].

    ROS contribute to the activation of autophagy after EMR. In the experiment of Liu and others, as described previously, pretreatment with antioxidant N-acetyl-cysteine (NAC) reduced the conversion of LC3-Ⅰ to LC3-Ⅱ and decreased the degradation of p62 in the RF-exposed group, which suggests that the enhanced autophagy by RF was achieved by increased ROS production[52]. There is strong consensus that increased ROS promotes the occurrence of autophagy, and Li Lulu et al.[70] have discussed the interactions between ROS and autophagy as well as the underlying mechanisms in detail. Briefly, the internal regulatory mechanisms of autophagy by ROS can be summarized as transcriptional and post-transcriptional regulation, which includes various molecular signal pathways such as ROS-FOXO3-LC3/BNIP3-autophagy, ROS-NRF2-P62-autophagy, ROS-HIF1-BNIP3/NIX-autophagy, and ROS-TIGAR-autophagy.

  • microRNAs (miRNAs) are a class of endogenous, 22-24 nucleotide-long noncoding RNA molecules, that affect protein synthesis by impairing both the stability and translation of specific mRNAs, and they are involved in many processes in cells, including autophagy[71-72].

    Down-regulated miR-30a activates autophagy after EMR through modulating the expression of autophagy-promoting gene beclin1. Among the previously identified microRNAs (miRNAs) in rat hippocampus that were sensitive to microwaves, we found that miR-30a was significantly down-regulated after exposure[73]. A study on the effects of a pulsed low-frequency EMF (LF-EMF, 75 Hz, 2 mT, 1.3 ms) exposure on miR-30a expression and downstream on beclin1 mRNA and protein levels was conducted in human neuroblastoma cells, and the researchers found that LF-EMF induced a significant reduction of miR-30a with a concomitant increase in beclin1 transcripts and its corresponding protein, which resulted in the activation of autophagy[51]. Studies have suggested that miR-30a negatively regulates the expression of beclin1 and Atg12, which results in a decreased level of autophagy[74-80]. Thus, down-regulated miR-30a may be an important mechanism of autophagy activation induced by EMR.

  • Currently, the potential health hazards caused by EMR have attracted great attention from public as well as the scientific community around the world. Studies have mainly focused on mechanisms of EMR injuries at the cellular and molecular levels. Autophagy, is a topic of strong interest in the biomedical field, and it contributes to basal cellular and tissue homeostasis and is essential for physiological responses to stresses. The research on the effects of EMR on autophagy and the roles of autophagy in EMR-induced injury is still in its infancy, and there are many problems that have yet to be solved. Due to the complicated parameters of EMR, the results from different laboratories are not comparable, which creates obstacles for the formulation of any guidelines and development of this field. Furthermore, the effects of EMR on autophagy are not only related to the EMR itself but also affected by cell types and cell microenvironments. However, there has been little research in this area, and the conclusions made by this study should be carefully evaluated. The effects of EMR on autophagy, the relevant regulatory mechanisms and the roles of autophagy in the EMR-induced damage will be investigated in future research.

  • HAO Yan Hui participated in the design, collected and analyzed the data. ZHAO Li and PENG Rui Yun conceived the review and helped to draft the manuscript. All authors read and approved the final manuscript.

  • No conflict of interest to declare.
