Measurement methods of PA can be divided into subjective and objective evaluation methods. Subjective methods include diaries, logs, and questionnaires; e.g., international physical activity questionnaires. Subjective measurement, as part of a self-report survey, is the most extensively used. The most common method for assessing the PA level is the questionnaire, but as a subjective measurement method, several kinds of bias often occur[7], such as the recall bias to quantify PA for children and elderly individuals. Therefore, objective methods, such as accelerometers, provide a considerably greater precision of measurement[8]. Thus, seeking efficient methods to quantify PA has become a necessity.
Objective methods include observations, doubly labeled water (DLW), motion sensors (e.g., pedometers and accelerometers), and heart rate (HR) monitors. DLW is the most effective and reliable method to measure the total energy expenditure of free-living conditions, which is the gold standard[9-10]. HR monitors are based on physiological sensors which is useful as a physiological variable because it linearly and proportionately increases with exercise intensity and subsequently with oxygen uptake[11]. Some studies have concluded that the energy expenditure can be predicted from HR after adjusting for age, sex, and body mass[12], because of the low correlation between energy expenditure and HR in light-intensity PA.
Movement sensors (e.g., pedometers and accelerometers) report their outcomes in activity counts per unit of time, which are the product of the frequency and intensity of movement. Therefore, movement sensors not only can provide temporal information regarding specific variables, such as the total amount, frequency, and duration of PA[13], but also monitor the accumulation of MVPA and/or sedentary behavior with the development of population-specific cut-off points for activity counts per minute. Early pedometers were mechanical with a 2D-vibration sensor; currently, 3D-electronic pedometers have replaced them and have become a popular way for people to keep track of their recommended 10, 000 daily steps; these are worn around the waist or on the wrist and include Omron™, Walking FIT™[14]. Among them, wrist pedometers, such as the Basis B1 health watch and Fit Flex, are popular and have been used as devices for monitoring PA. They are effective in detecting the total movement over a given timeframe, but may be less effective in distinguishing the types of PA. In other words, they might be effective in detecting the duration of walking or sitting, but are unable to detect cycling or the difference between sitting and watching TV/working[15]. However, cycling, which is classified as a MVPA, is poorly measured by accelerometers[16].
The growing affordable, multi-sensor technologies, including the combination of physiological, contextual, and motion sensors, seem to have a great potential in recording PA, sleeping time, HR, and other daily activities. Recently, the use of smartphones with applications (apps) or a WeChat tool has also become popular. The users need not buy any pedometer device because a smartphone directly provides the pedometer function. A comparative study of accuracy between pedometers, wearable devices, and smartphone apps reported the relative differences in mean steps during 500-and 1, 500-step trails ranging from -0.3% to 1.0%, -22.7% to 1.5%, and -6.7% to 6.2%. Compared with actual step counts, data from wearable devices differed more than from smartphone apps[17]. Moreover, an assessment using a questionnaire overestimated PA strata than that using an objective method, such as using a pedometer[18]. Gradually, the development of ICT has provided new measures for assessing PA. The researchers have begun to try ICT methods, which are gradually being used in epidemiologic research to validate traditional methods, such as questionnaires (Table 1).
Table 1. Common Types of Measuring Physical Activity
Common Types 2D Pedometers 3D Pedometers Sport Band Smartphone-pedometers Apps Watch-pedometers Movement Mechanical-pendulum sensor 3D-acceleration electronic sensor Acceleration sensor + Physiological sensor + GPS Acceleration sensor Acceleration sensor + GPS 3D-acceleration electronic sensor + physiological sensor + GPS Data storage None Yes Yes Yes Yes Yes Calories, number of steps, distance Yes Yes Yes Yes Yes Yes Speed None None Yes Yes Yes Yes Wearable mode Must be vertical with a belt clip Free or use a band fixed on the wrist Wrist Free - Wrist Brand Manpo-meter from Japan Walking FIT, Omron Fitbit, Mi band WeChat movement, QQ movement Nike + running, Codoon, Langdong Apple watch Other functions None Timing Heart rate, sleep time, cycling - Cycling, climbing (partial have) Heart rate, sleep time
doi: 10.3967/bes2017.062
Measurement and Assessment of Physical Activity by Information and Communication Technology
-
Abstract: This study provides explorative insights into the information and communication technology (ICT) for promoting the physical activity level. ICT has provided innovative ideas and perspectives for PA measurement, assessment, evaluation and health intervention. ICT that aims to increase exercise for the entire population should be of a well-oriented and easy-to-use design with the options of tailored and personalized feedback, coaching, and ranking and supporting; it should be capable of setting goals and working with a schedule and be accompanied by a website to provide overviews of the users' exercise results and progress.
-
Key words:
- Physical activity /
- Measurement /
- Assessment /
- Information and communication technology
-
Table 1. Common Types of Measuring Physical Activity
Common Types 2D Pedometers 3D Pedometers Sport Band Smartphone-pedometers Apps Watch-pedometers Movement Mechanical-pendulum sensor 3D-acceleration electronic sensor Acceleration sensor + Physiological sensor + GPS Acceleration sensor Acceleration sensor + GPS 3D-acceleration electronic sensor + physiological sensor + GPS Data storage None Yes Yes Yes Yes Yes Calories, number of steps, distance Yes Yes Yes Yes Yes Yes Speed None None Yes Yes Yes Yes Wearable mode Must be vertical with a belt clip Free or use a band fixed on the wrist Wrist Free - Wrist Brand Manpo-meter from Japan Walking FIT, Omron Fitbit, Mi band WeChat movement, QQ movement Nike + running, Codoon, Langdong Apple watch Other functions None Timing Heart rate, sleep time, cycling - Cycling, climbing (partial have) Heart rate, sleep time -
[1] WHO. Global Strategy on Diet, Physical Activity and Health L. 2004. 05 http://www.who.int/dietphysicalactivity/en/. [2017-05-25] [2] Bauman A, Merom D, Bull FC, et al. Updating the Evidence for Physical Activity: Summative Reviews of the Epidemiological Evidence, Prevalence, and Interventions to Promote 'Active Aging'. Gerontologist, 2016, 56, S268-80. doi: 10.1093/geront/gnw031 [3] Cook I, Alberts M, Lambert EV. Relationship between adiposity and pedometer-assessed ambulatory activity in adult, rural African women. Int J Obes, 2008, 32; 1327-30. doi: 10.1038/ijo.2008.26 [4] Warburton DE, Charlesworth S, Ivey A, et al. A systematic review of the evidence for Canada's Physical Activity Guidelines for Adults. Int J Behav Nutr Phys Act, 2010, 7, 39. doi: 10.1186/1479-5868-7-39 [5] WHO. Prevalence of insufficient physical activity. 2010 http://www.who.int/gho/ncd/risk_factors/physical_activity/en/. [2017-05-25] [6] UNION I T. ICT facts and figures 2016. 2016 http://www.itu.int/en/ITU-D/Statistics/Documents/facts/ICTFactsFigures2016.pdf. [2017-05-25] [7] Sallis JF, Saelens BE. Assessment of physical activity by self-report: status, limitations, and future directions. Res Q Exerc Sport, 2000, 71, S1-14. https://www.ncbi.nlm.nih.gov/pubmed/?term=Assessment+of+physical+activity+by+self-report%3A+status%2C+limitations%2C+and+future+directions. [8] Riddoch CJ, Mattocks C, Deere K, et al. Objective measurement of levels and patterns of physical activity. Arch Dis Child, 2007, 92:963-9. doi: 10.1136/adc.2006.112136 [9] Bergouignan A, Momken I, Lefai E, et al. Activity energy expenditure is a major determinant of dietary fat oxidation and trafficking, but the deleterious effect of detraining is more marked than the beneficial effect of training at current recommendations. Am J Clin Nutr, 2013, 98:648-58. doi: 10.3945/ajcn.112.057075 [10] Mensah K, Maire A, Oppert JM, et al. Assessment of sedentary behaviors and transport-related activities by questionnaire: a validation study. BMC Public Health, 2016, 16, 753. doi: 10.1186/s12889-016-3412-3 [11] Chen KY, Janz KF, Zhu W, et al. Redefining the roles of sensors in objective physical activity monitoring. Med Sci Sports Exerc, 2012, 44, S13-23. doi: 10.1249/MSS.0b013e3182399bc8 [12] Keytel LR, Goedecke JH, Noakes TD, et al. Prediction of energy expenditure from heart rate monitoring during submaximal exercise. J Sports Sci, 2005, 23:289-97. doi: 10.1080/02640410470001730089 [13] Westerterp KR. Assessment of physical activity: a critical appraisal. Eur J Appl Physiol, 2009, 105: 823-8. http://cat.inist.fr/?aModele=afficheN&cpsidt=21266848 [14] Husted HM, Llewellyn TL. The Accuracy of Pedometers in Measuring Walking Steps on a Treadmill in College Students. Int J Exerc Sci, 2017, 10:146-53. http://digitalcommons.wku.edu/cgi/viewcontent.cgi?article=1904&context=ijes [15] Kelly P, Fitzsimons C, Baker G. Should we reframe how we think about physical activity and sedentary behaviour measurement? Validity and reliability reconsidered. Int J Behav Nutr Phys Act, 2016, 13, 32. doi: 10.1186/s12966-016-0351-4 [16] Slootmaker SM, Schuit AJ, Chinapaw MJM, et al. Disagreement in physical activity assessed by accelerometer and self-report in subgroups of age, gender, education and weight status. Int J Beha Nutr Phys Act, 2009, 6, 17. doi: 10.1186/1479-5868-6-17 [17] Case MA, Burwick HA, Volpp KG, et al. Accuracy of smartphone applications and wearable devices for tracking physical activity data. JAMA, 2015, 313:625-6. doi: 10.1001/jama.2014.17841 [18] Colpani V, Spritzer PM, Lodi AP, et al. Physical activity in climacteric women: comparison between self-reporting and pedometer. Rev Saúde Pública, 2014, 48:258-65. doi: 10.1590/S0034-8910.2014048004765 [19] Sweet SN, Fortier MS. Improving Physical Activity and Dietary Behaviours with Single or Multiple Health Behaviour Interventions? A Synthesis of Meta-Analyses and Reviews. Int J Environ Res Public Health, 2010, 7:1720-43. doi: 10.3390/ijerph7041720 [20] King AC, Haskell WL, Taylor CB, et al. Group-vs. home-based exercise training in healthy older men and women. JAMA, 1991, 266:1535-42. doi: 10.1001/jama.1991.03470110081037 [21] Noell J, Glasgow RE. Interactive technology applications for behavioral counseling1: Issues and opportunities for health care settings. Am J Prev Med, 1999, 17:269-74. doi: 10.1016/S0749-3797(99)00093-8 [22] Patrick K. Information technology and the future of preventive medicine. Am J Prev Med, 2000, 19:132-5. doi: 10.1016/S0749-3797(00)00189-6 [23] Marcus B, Owen N, Forsyth L, et al. Physical activity interventions using mass media, print media, and information technology. Am J Prev Med, 1998, 15:362-78. doi: 10.1016/S0749-3797(98)00079-8 [24] Writing Group for the Activity Counseling Trial Research Group. Effects of physical activity counseling in primary care: The activity counseling trial: a randomized controlled trial. JAMA, 2001, 286:677-87. doi: 10.1001/jama.286.6.677 [25] Marcus BH, Lewis BA, Williams DM, et al. Step into Motion: A randomized trial examining the relative efficacy of Internet vs. print-based physical activity interventions. Contemp Clin Trials, 2007, 28:737-47. doi: 10.1016/j.cct.2007.04.003 [26] Cushing CC, Steele RG. A Meta-Analytic Review of eHealth Interventions for Pediatric Health Promoting and Maintaining Behaviors. J Pediatr Psychol, 2010, 35:937-49. doi: 10.1093/jpepsy/jsq023 [27] Vandelanotte C, M LLER A M, SHORT C E, et al. Past, Present, and Future of eHealth and mHealth Research to Improve Physical Activity and Dietary Behaviors. J Nutr Educ Behav, 2016, 48:219-28, e1. doi: 10.1016/j.jneb.2015.12.006 [28] Rehman H, Kamal AK, Sayani S, et al. Using Mobile Health (mHealth) Technology in the Management of Diabetes Mellitus, Physical Inactivity, and Smoking. Curr Atheroscler Rep, 2017, 19, 16. doi: 10.1007/s11883-017-0650-5 [29] Davies CA, Spence JC, Vandelanotte C, et al. Meta-analysis of internet-delivered interventions to increase physical activity levels. Int J Behav Nutr PhysAct, 2012, 9, 52. doi: 10.1186/1479-5868-9-52 [30] Webb TL, Joseph J, Yardley L, et al. Using the Internet to Promote Health Behavior Change: A Systematic Review and Meta-analysis of the Impact of Theoretical Basis, Use of Behavior Change Techniques, and Mode of Delivery on Efficacy. J Med Internet Res, 2010, 12, e4. doi: 10.2196/jmir.1376 [31] Conn VS, Hafdahl AR, Mehr DR. Interventions to Increase Physical Activity among Healthy Adults: Meta-Analysis of Outcomes. Am j Public Health, 2011, 101:751-8. doi: 10.2105/AJPH.2010.194381 [32] Brouwer W, Kroeze W, Crutzen R, et al. Which Intervention Characteristics are Related to More Exposure to Internet-Delivered Healthy Lifestyle Promotion Interventions? A Systematic Review. J Med Internet Res, 2011, 13, e2. doi: 10.2196/jmir.1639 [33] S. FOX M D. Pew Research Center's Internet & American Life Project, Washington DC. Mobile health 2012. https://www.benton.org/taxonomy/term/2126 [34] Bender JL, Yue RY, To MJ, et al. A Lot of Action, But Not in the Right Direction: Systematic Review and Content Analysis of Smartphone Applications for the Prevention, Detection, and Management of Cancer. J Med Internet Res, 2013, 15, e287. doi: 10.2196/jmir.2661 [35] Conroy DE, Yang CH, Maher JP. Behavior Change Techniques in Top-Ranked Mobile Apps for Physical Activity. Am J Prev Med, 2014, 46:649-52. doi: 10.1016/j.amepre.2014.01.010 [36] Coughlin SS, Whitehead M, Sheats JQ, et al. A Review of Smartphone Applications for Promoting Physical Activity. Jacobs J Community Med, 2016, 2, 021. http://www.ncbi.nlm.nih.gov/pmc/articles/pmid/27034992/ [37] Bort-Roig J, Gilson ND, Puig-Ribera A, et al. Measuring and Influencing Physical Activity with Smartphone Technology: A Systematic Review. Sports Med, 2014, 44:671-86. doi: 10.1007/s40279-014-0142-5 [38] Middelweerd A, van der Laan DM, van Stralen MM, et al. What features do Dutch university students prefer in a smartphone application for promotion of physical activity? A qualitative approach. Int J Behav Nutr Phys Act, 2015, 12, 31. doi: 10.1186/s12966-015-0189-1 [39] Glynn LG, Hayes PS, Casey M, et al. Effectiveness of a smartphone application to promote physical activity in primary care: the SMART MOVE randomised controlled trial. Br J Gen Pract, 2014, 64, e384-e91. doi: 10.3399/bjgp14X680461 [40] Kirwan M, Duncan MJ, Vandelanotte C, et al. Using Smartphone Technology to Monitor Physical Activity in the 10, 000 Steps Program: A Matched Case–Control Trial. J Med Internet Res, 2012, 14, e55. doi: 10.2196/jmir.1950 [41] Ehlers DK, Huberty JL. Middle-Aged Women's Preferred Theory-Based Features in Mobile Physical Activity Applications. J Phys Act Health, 2014, 11:1379-85. doi: 10.1123/jpah.2012-0435 [42] Rabin C, Bock B. Desired Features of Smartphone Applications Promoting Physical Activity. Telemed J E Health, 2011, 17:801-3. doi: 10.1089/tmj.2011.0055 [43] King AC, Hekler EB, Castro CM, et al. Exercise advice by humans versus computers: Maintenance effects at 18 months. Health Psychol, 2014, 33:192-6. doi: 10.1037/a0030646 [44] Lyons EJ, Lewis ZH, Mayrsohn BG, et al. Behavior Change Techniques Implemented in Electronic Lifestyle Activity Monitors: A Systematic Content Analysis. J Med Internet Res, 2014, 16, e192. doi: 10.2196/jmir.3469 [45] Webb RC, Bonifas AP, Behnaz A, et al. Ultrathin conformal devices for precise and continuous thermal characterization of human skin. Nat Mater, 2013, 12:938-44. doi: 10.1038/nmat3755 [46] Trung TQ, Lee NE. Flexible and Stretchable Physical Sensor Integrated Platforms for Wearable Human-Activity Monitoringand Personal Healthcare. Adv Mater, 2016, 28:4338-72. doi: 10.1002/adma.v28.22 [47] Pasinetti GM, Ksiezak-Reding H, Santa-Maria I, et al. Development of a grape seed polyphenolic extract with anti-oligomeric activity as a novel treatment in progressive supranuclear palsy and other tauopathies. J Neurochem, 2010, 114:1557-68. doi: 10.1111/j.1471-4159.2010.06875.x [48] Crowley O, Pugliese L, Kachnowski S. The Impact of Wearable Device Enabled Health Initiative on Physical Activity and Sleep. Cureus, 2016, 8, e825. http://assets.cureus.com/uploads/original_article/pdf/4832/1476193389-20161011-5148-1bjv12s.pdf [49] Bravata DM, Smith-Spangler C, Sundaram V, et al. Using pedometers to increase physical activity and improve health: A systematic review. JAMA, 2007, 298:2296-304. doi: 10.1001/jama.298.19.2296 [50] Pekmezi D, Dunsiger S, Gaskins R, et al. Feasibility and acceptability of using pedometers as an intervention tool for Latin. J Phys Act Health, 2013, 10:451-7. doi: 10.1123/jpah.10.3.451 [51] Mendoza L, Horta P, Espinoza J, et al. Pedometers to enhance physical activity in COPD: a randomised controlled trial. Eur Respir J, 2015, 45:347-54. doi: 10.1183/09031936.00084514 [52] Whitney R, Bhan H, Persadie N, et al. Feasibility of Pedometer Use to Assess Physical Activity and Its Relationship With Quality of Life in Children With Epilepsy: A Pilot Study. Pediatr Neurol, 2013, 49:370-3. doi: 10.1016/j.pediatrneurol.2013.06.002 [53] Rollo ME, Aguiar EJ, Williams RL, et al. eHealth technologies to support nutrition and physical activity behaviors in diabetes self-management. Diabetes Metab Syndr Obes, 2016, 9:381-90. doi: 10.2147/DMSO [54] Doherty AR, Kelly P, Kerr J, et al. Using wearable cameras to categorise type and context of accelerometer-identified episodes of physical activity. Int J Behav Nutr Phys Act, 2013, 10, 22. doi: 10.1186/1479-5868-10-22 [55] Årsand E, Muzny M, Bradway M, et al. Performance of the First Combined Smartwatch and Smartphone Diabetes Diary Application Study. J Diabetes Sci Technol, 2015, 9:556-63. doi: 10.1177/1932296814567708 [56] Deutsch JE, Myslinski MJ, Kafri M, et al. Feasibility of Virtual Reality Augmented Cycling for Health Promotion of People Post-Stroke. J Neurol Phys Ther, 2013, 37:118-24. doi: 10.1097/NPT.0b013e3182a0a078 [57] Lin CY, Chang YM. Interactive augmented reality using Scratch 2.0 to improve physical activities for children with developmental disabilities. Res Dev Disabil, 2015, 37:1-8. doi: 10.1016/j.ridd.2014.10.016 [58] Miller KJ, Adair BS, Pearce AJ, et al. Effectiveness and feasibility of virtual reality and gaming system use at home by older adults for enabling physical activity to improve health-related domains: a systematic review. Age Ageing, 2014, 43:188-95. doi: 10.1093/ageing/aft194 [59] Hakala S, Rintala A, Immonen J, et al. Effectiveness of technology-based distance interventions promoting physical activity: Systematic review, meta-analysis and meta-regression. Eur J Phys Rehabil Med, 2017, 49:97-105. doi: 10.2340/16501977-2195 [60] Bravata DM, Smith-Spangler C, Sundaram V, et al. Using pedometers to increase physical activity and improve health: a systematic review. JAMA, 2007, 298:2296-304. doi: 10.1001/jama.298.19.2296 [61] Coughlin SS, Whitehead M, Sheats JQ, et al. Smartphone Applications for Promoting Healthy Diet and Nutrition: A Literature Review. Jacobs J Food Nutr, 2015, 2, 021. http://europepmc.org/abstract/MED/26819969 [62] Flores Mateo G, Granado-Font E. Mobile Phone Apps to Promote Weight Loss and Increase Physical Activity: A Systematic Review and Meta-Analysis. J Med Internet Res, 2015, 17, e253. doi: 10.2196/jmir.4836 [63] Richards J, Thorogood M, Hillsdon M, et al. Face-to-face versus remote and web 2. 0 interventions for promoting physical activity. Cochrane Database Syst Rev, 2013, 30, CD010393. http://www.cochrane.org/CD010393/VASC_face-to-face-versus-remote-and-web-2.0-interventions-for-promoting-physical-activity
